155
Data Manager Operations Scanner DataViewer Operation
12.7 Scanner DataViewer Operation
The Scanner DataViewer allows you to review saved scanner data files (Figure 12-18). To open
saved Scanner data files, select the Scanner Data Folder menu option from the Data Manager
main menu.
Scanner DataViewer - Opens .pids, .scm, .scs, .scp and .spm file extensions
1— Menu bar
2— Display toolbar
3— Graph display
4— Properties icon
5— Vertical Scroll bar
6— Zoom controls
7— Slider bar
8— Navigation toolbar
9— Parameter text list
10—Parameter configuration tabs
Figure 12-18 Scanner Data Viewer
