Introduction Features and Specifications
2.1.3 Scan Module (Wireless)
1— Data Cable Connector
2— Vehicle Power LED (green)
3— Communication Issue LED (red)
4— Bluetooth LED (green)
5— Memory Card Port (remove protective hand grip for access)
6— Universal Serial Bus (USB) Jack (remove protective hand grip for access)
Figure 2-4 Scan Module
($//%
