175
System Settings Operations Data Backup
14.3 Data Backup
Selecting Data Backup from the Systems Settings main menu provides two options, backup and
restore.
14.3.1 Backup
The Backup option allows you to back up your saved data to a file on the internal hard drive, or to
an external drive (e.g. USB flash drive). This option can be used as general maintenance to
ensure you have a safe backup of your saved data, or if a issue occurs where a system restore is
necessary and you need to retain your saved data. The following types of data are backed up:
• ShopStream Data (saved movie/data files)
• Lab Scope Settings (presets)
• Vehicle History Records and Favorites
z To Backup Information:
1. From the Home screen select System Settings.
2. From the System Settings main menu select Data Backup > Backup.
The destination drive dialog box opens (Figure 14-9).
3. Select a drive destination.
i Drive designations (e.g. E:/, F:/ etc.), are only visible when external drives are connected to the
diagnostic tool.
Figure 14-9
A progress screen is displayed as the backup file is saved to the root of the drive selected with a
file extension of .sna. Then a confirmation screen is displayed.
4. Select OK to complete the procedure.
