Sony DCR-VX2000 - Vap Sensor; Printed Wiring Board

DCR-VX2000/VX2000E
4-75 4-76
VAP SENSOR
SE-108
SE-108 (VAP SENSOR) PRINTED WIRING BOARD
— Ref. No. SE-108 Board; 1,000 Series —
For printed wiring board
• Refer to page 4-117 for parts location.
• This board is six-layer print board. However, the pat-
terns of layers two to five have not been included in
the diagram.
There are few cases that the part printed on this
diagram isn’t mounted in this model.
FT-090
(REMOTE)
MI-038
(MIC IN)
MA-386
(AUDIO AMP)
LB-065
(BACK LIGHT)
CK-093
(KEY IN)
PD-126
(RGB DRIVE/TG)
HL-011
(LCD DRIVE)
CD-254
(CCD IMAGER)
FK-076
(CONTROL SWITCH)
INVERTER TRANSFORME
R
UNIT
SE-108
(VAP SENSOR)
1-678-057-
21
D576 D575D577
S501 S502 S503
BACK LIGHT SPOT LIGHT
FADER
FP-189 FLEXIBLE BOARD
1-678-056-
21
S550
INDEX MARK
S551
S552
D551
S550
S551
PUSH AUTO
S552
AUTO
MAN
INFINITY
FP-188 FLEXIBLE BOARD
D552
D550
1
6
FP-201
FP-202
FP-193
FP-190
FP-196
FP-195
FP-191
FP-189
FP-199
FP-198
FP-200
FP-194
FP-188
CONTROL SWITCH BLOCK
(ED-4980)
