Sony DCR-VX2000 - Cabinet (L) Block Assembly, Mechanism; For Force Eject of Cassette and Vtr Section Check

2-5
2-5. CABINET (L) BLOCK ASSEMBLY, MECHANISM DECK,
VC-242, DD-138, JK-190 BOARDS
(FOR FORCE EJECT OF CASSETTE AND VTR SECTION CHECK)

DD-
138
V
C
-242
B
oard
1 Screw
(M2 × 5),
spring bolt
6 Cabinet (L)
block assembly
2 Screw
(M2 × 5),
spring bolt
3 Screw
(M2 × 5),
spring bolt
4 Two screws
(M2 × 3),
spring bolt
9 Four screws
(M2 × 3),
spring bolt
1 Two screws
(M2 × 5),
spring bolt
4 Screw
(M2 × 3),
spring bolt
3 Screw
(M2 × 3),
spring bolt
5 Flexible retainer
1 FP-193 flexible
board (27P)
7 FP-186 flexible
board (80P)
qa CD-254 board
(50P)
qs Battery terminal board (4P)
qd DC-IN connector (3P)
qf Mechanism deck,
VC-242, DD-138 board,
MD frame assembly
2 FP-200 flexible
board (10P)
6 FP-187 flexible
board (50P)
4 FP-191 flexible
board (60P)
8 JK-190 board (40P)
q; Claw
5 Three screws
(M2 × 5),
spring bolt
(FOR FORCE EJECT OF CASSETTE)
(FOR VTR SECTION CHECK)
2 JK-190 board,
JK frame
3 Two screws
(M2 × 3),
spring bolt
5 DD-138 board
6 Mechanism deck,
VC-242 board,
MD frame assembly
