5-52
• PANEL Cr BIST Check
Order Page
Address
Data Procedure
1 3 10 99 Set the data, and press PAUSE
button.
2 3 12 10 Set the data, and press PAUSE
button.
3 3 12 00 Set the data, and press PAUSE
button.
4 3 13 04 Set the data, and press PAUSE
button.
5 3 14 Check that the data is the
following value.
NTSC model: 2E
PAL model: 33
6 3 15 Check that the data is the
following value.
NTSC model: 34
PAL model: DD
7 3 If the data of address 14 and
address 15 are correct, IC301
PANEL Cr playback system is
normal.
• PANEL Cb BIST Check
Order Page
Address
Data Procedure
1 3 10 9A Set the data, and press PAUSE
button.
2 3 12 10 Set the data, and press PAUSE
button.
3 3 12 00 Set the data, and press PAUSE
button.
4 3 13 04 Set the data, and press PAUSE
button.
5 3 14 Check that the data is the
following value.
NTSC model: A9
PAL model: AA
6 3 15 Check that the data is the
following value.
NTSC model: 39
PAL model: 03
7 3 If the data of address 14 and
address 15 are correct, IC301
PANEL Cb playback system is
normal.
1-5. IC301 ENCODER BIST Check
• Preparations
Order Page
Address
Data Procedure
1 0 01 01 Set the data.
2 8 21 0F Set the data, and press PAUSE
button.
• ENCODER Ya BIST Check
Order Page
Address
Data Procedure
1 3 10 8B Set the data, and press PAUSE
button.
2 3 12 10 Set the data, and press PAUSE
button.
3 3 12 00 Set the data, and press PAUSE
button.
4 3 13 04 Set the data, and press PAUSE
button.
5 3 14 Check that the data is the
following value.
NTSC model: FD
PAL model: 58
6 3 15 Check that the data is the
following value.
NTSC model: 3E
PAL model: BE
7 3 If the data of address 14 and
address 15 are correct, IC301
ENCORDER Ya playback
system is normal.
• ENCODER Yb BIST Check
Order Page
Address
Data Procedure
1 3 10 8C Set the data, and press PAUSE
button.
2 3 12 10 Set the data, and press PAUSE
button.
3 3 12 00 Set the data, and press PAUSE
button.
4 3 13 04 Set the data, and press PAUSE
button.
5 3 14 Check that the data is the
following value.
NTSC model: 94
PAL model: A1
6 3 15 Check that the data is the
following value.
NTSC model: D6
PAL model: ED
7 3 If the data of address 14 and
address 15 are correct, IC301
ENCORDER Yb playback
system is normal.
