Sony DCR-VX2000 - D ( D )

6-25
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R2173 1-218-990-11 SHORT 0
R2174 1-218-990-11 SHORT 0
R2175 1-218-990-11 SHORT 0
R2176 1-218-990-11 SHORT 0
R2177 1-218-977-11 RES-CHIP 100K 5% 1/16W
R2178 1-218-977-11 RES-CHIP 100K 5% 1/16W
R2179 1-218-977-11 RES-CHIP 100K 5% 1/16W
R2180 1-218-977-11 RES-CHIP 100K 5% 1/16W
R2181 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R2182 1-218-953-11 RES-CHIP 1K 5% 1/16W
R2183 1-218-941-11 RES-CHIP 100 5% 1/16W
R2184 1-218-990-11 SHORT 0
************************************************************
A-7074-399-A SE-108 BOARD, COMPLETE
**********************
(Ref.No.;1000Series)
< CAPACITOR >
C600 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C601 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
< CONNECTOR >
CN600 1-766-336-21 CONNECTOR, FFC/FPC 6P
< COIL >
L600 1-414-754-11 INDUCTOR 10uH
< SENSOR >
SE600 1-803-042-31 SENSOR, ANGULAR VELOCITY
SE601 1-803-042-41 SENSOR, ANGULAR VELOCITY
************************************************************
A-7096-157-A VC-242 BOARD, COMPLETE (SERVICE)
**********************
(Ref.No.;10000Series)
************************************************************
Electrical parts list of the VC-242 board
are not shown.
pages 6-27 to 6-36 are not shown.
PD-126 SE-108 VC-242
