6-24
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-7096-158-A PD-126 BOARD, COMPLETE (SERVICE)
**********************
(Ref.No.;20000Series)
< CAPACITOR >
C2101 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C2102 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2103 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2104 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2105 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2107 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C2108 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2109 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2110 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2111 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C2112 1-125-838-91 CERAMIC CHIP 2.2uF 10% 6.3V
C2113 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C2114 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2115 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C2116 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C2117 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C2118 1-125-838-91 CERAMIC CHIP 2.2uF 10% 6.3V
C2119 1-125-838-91 CERAMIC CHIP 2.2uF 10% 6.3V
C2120 1-125-838-91 CERAMIC CHIP 2.2uF 10% 6.3V
C2123 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C2124 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2125 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C2126 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C2127 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2128 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C2129 1-216-295-91 SHORT 0 (Note)
C2130 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2133 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C2181 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C2182 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2183 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C2184 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2185 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2186 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN2100 1-794-378-21 PIN, CONNECTOR 14P
CN2101 1-794-377-21 PIN, CONNECTOR 8P
* CN2103 1-778-155-11 CONNECTOR, FFC/FPC (ZIF) 7P
* CN2104 1-778-172-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN2105 1-764-704-21 CONNECTOR, FFC/FPC (LIF) 5P
< DIODE >
D2101 8-719-073-01 DIODE MA111-TX
D2102 8-713-102-80 DIODE 1T369-01-T8A
D2104 8-719-050-42 DIODE RD3.3UM-T1B
D2181 8-719-059-47 DIODE PG1111R-TR
< IC >
IC2101 8-759-660-93 IC RB5P004AM1
IC2103 8-752-403-84 IC CXD3505R-T4
< COIL >
L2101 1-414-755-11 INDUCTOR 22uH
L2102 1-414-754-11 INDUCTOR 10uH
L2103 1-414-754-11 INDUCTOR 10uH
L2104 1-410-998-31 INDUCTOR 2.7uH
L2181 1-412-056-11 INDUCTOR 4.7uH
L2182 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q2101 8-729-427-74 TRANSISTOR XP4601-TXE
Q2102 8-729-037-74 TRANSISTOR UN9213J-(TX).SO
Q2103 8-729-427-74 TRANSISTOR XP4601-TXE
Q2104 8-729-041-23 TRANSISTOR NDS356AP
Q2109 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q2111 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q2112 8-729-048-77 TRANSISTOR XP4313-(TX).SO
Q2181 8-729-042-72 TRANSISTOR UN9214J-(K8).SO
Q2182 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q2183 8-729-042-59 TRANSISTOR UN9112J-(K8).SO
< RESISTOR >
R2111 1-218-985-11 RES-CHIP 470K 5% 1/16W
R2112 1-218-985-11 RES-CHIP 470K 5% 1/16W
R2113 1-218-990-11 SHORT 0
R2114 1-218-967-11 RES-CHIP 15K 5% 1/16W
R2115 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R2116 1-218-973-11 RES-CHIP 47K 5% 1/16W
R2117 1-218-975-11 RES-CHIP 68K 5% 1/16W
R2118 1-218-969-11 RES-CHIP 22K 5% 1/16W
R2119 1-218-975-11 RES-CHIP 68K 5% 1/16W
R2122 1-218-989-11 RES-CHIP 1M 5% 1/16W
R2123 1-218-990-11 SHORT 0
R2124 1-218-977-11 RES-CHIP 100K 5% 1/16W
R2129 1-218-990-11 SHORT 0
R2134 1-218-929-11 RES-CHIP 10 5% 1/16W
R2136 1-218-929-11 RES-CHIP 10 5% 1/16W
R2137 1-218-929-11 RES-CHIP 10 5% 1/16W
R2138 1-218-941-11 RES-CHIP 100 5% 1/16W
R2143 1-218-965-11 RES-CHIP 10K 5% 1/16W
R2144 1-218-985-11 RES-CHIP 470K 5% 1/16W
R2146 1-218-990-11 SHORT 0
R2147 1-218-990-11 SHORT 0
R2148 1-218-965-11 RES-CHIP 10K 5% 1/16W
R2153 1-218-990-11 SHORT 0
R2157 1-218-989-11 RES-CHIP 1M 5% 1/16W
R2158 1-218-975-11 RES-CHIP 68K 5% 1/16W
R2159 1-218-979-11 RES-CHIP 150K 5% 1/16W
R2160 1-218-988-11 RES-CHIP 820K 5% 1/16W
R2162 1-218-990-11 SHORT 0
R2163 1-218-990-11 SHORT 0
R2165 1-218-990-11 SHORT 0
R2166 1-218-965-11 RES-CHIP 10K 5% 1/16W
R2168 1-218-990-11 SHORT 0
R2169 1-218-990-11 SHORT 0
R2170 1-218-977-11 RES-CHIP 100K 5% 1/16W
R2172 1-218-990-11 SHORT 0
Note : Resistor is mounted to the location where C2129 is printed.
PD-126
