6-23
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R1153 1-218-971-11 RES-CHIP 33K 5% 1/16W
R1154 1-218-965-11 RES-CHIP 10K 5% 1/16W
R1155 1-218-965-11 RES-CHIP 10K 5% 1/16W
R1157 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R1158 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R1159 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R1160 1-218-953-11 RES-CHIP 1K 5% 1/16W
R1161 1-218-953-11 RES-CHIP 1K 5% 1/16W
R1162 1-208-912-11 METAL CHIP 11K 0.5% 1/16W
R1163 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R1164 1-208-912-11 METAL CHIP 11K 0.5% 1/16W
R1168 1-218-964-11 RES-CHIP 8.2K 5% 1/16W
R1169 1-208-701-11 METAL CHIP 5.6K 0.5% 1/16W
R1170 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R1171 1-218-964-11 RES-CHIP 8.2K 5% 1/16W
R1172 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R1173 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R1174 1-218-971-11 RES-CHIP 33K 5% 1/16W
R1175 1-218-971-11 RES-CHIP 33K 5% 1/16W
R1176 1-218-971-11 RES-CHIP 33K 5% 1/16W
R1177 1-218-953-11 RES-CHIP 1K 5% 1/16W
R1178 1-218-968-11 RES-CHIP 18K 5% 1/16W
R1179 1-218-971-11 RES-CHIP 33K 5% 1/16W
R1180 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R1181 1-218-965-11 RES-CHIP 10K 5% 1/16W
R1182 1-218-965-11 RES-CHIP 10K 5% 1/16W
< SWITCH >
S1100 1-572-473-11 SWITCH, TACTIL
************************************************************
A-7074-411-A MI-O38 BOARD, COMPLETE
**********************
(Ref.No.;1000Series)
< CAPACITOR >
C700 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C701 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C702 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C703 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C704 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C705 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C706 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C709 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C710 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C711 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
< CONNECTOR >
* CN700 1-580-057-11 PIN, CONNECTOR (SMD) 4P
* CN701 1-580-057-11 PIN, CONNECTOR (SMD) 4P
CN702 1-573-990-21 CONNECTOR, BOARD TO BOARD 10P
* CN703 1-750-339-21 CONNECTOR, FFC/FPC (ZIF) 14P
< TRANSISTOR >
Q700 8-729-140-75 TRANSISTOR 2SD999-T1-CLCK
Q701 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q702 8-729-403-35 TRANSISTOR UN5113-TX
Q703 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q704 8-729-402-42 TRANSISTOR UN5213-TX
Q705 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q706 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q707 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
< RESISTOR >
R700 1-218-847-11 METAL CHIP 1K 0.5% 1/16W
R701 1-218-847-11 METAL CHIP 1K 0.5% 1/16W
R702 1-218-880-11 METAL CHIP 24K 0.5% 1/16W
R703 1-218-894-11 METAL CHIP 91K 0.5% 1/16W
R704 1-218-880-11 METAL CHIP 24K 0.5% 1/16W
R705 1-218-894-11 METAL CHIP 91K 0.5% 1/16W
R706 1-216-313-00 METAL CHIP 8.2 5% 1/10W
R707 1-218-949-11 RES-CHIP 470 5% 1/16W
R708 1-218-947-11 RES-CHIP 330 5% 1/16W
R713 1-218-965-11 RES-CHIP 10K 5% 1/16W
R714 1-218-965-11 RES-CHIP 10K 5% 1/16W
R715 1-218-965-11 RES-CHIP 10K 5% 1/16W
R716 1-218-990-11 SHORT 0
R717 1-218-990-11 SHORT 0
************************************************************
A-7074-408-A MK-014 BOARD, COMPLETE
***********************
(Ref.No.;1000Series)
< CONNECTOR >
CN001 1-779-327-11 CONNECTOR, FFC/FPC 6P
< DIODE >
D003 8-719-061-82 DIODE TLSU1002(TPX1,SONY)
D004 8-719-073-03 DIODE MA8082-(K8).S0
< RESISTOR >
R001 1-218-950-11 RES-CHIP 560 5% 1/16W
R006 1-218-969-11 RES-CHIP 22K 5% 1/16W
< SWITCH >
S001 1-771-138-61 SWITCH, KEY BOARD(GAIN)
S002 1-771-138-61 SWITCH, KEY BOARD(SHUTTER SPEED)
S003 1-771-138-61 SWITCH, KEY BOARD(WHT BAL)
S004 1-771-138-61 SWITCH, KEY BOARD(AE SHIFT)
S005 1-762-648-21 SWITCH, SLIDE(AUTOLOCK/HOLD)
************************************************************
A-7074-407-A MS-049 BOARD, COMPLETE
***********************
(Ref.No.;20000Series)
< CONNECTOR >
CN775 1-766-644-21 CONNECTOR, FFC/FPC 8P
CN776 1-793-641-11 CONNECTOR, MEMORY STICK
< RESISTOR >
R1001 1-216-295-91 SHORT 0
R1002 1-216-864-11 METAL CHIP 0 5% 1/16W
R1003 1-218-990-11 SHORT 0
R1004 1-216-864-11 METAL CHIP 0 5% 1/16W
************************************************************
MA-386 MI-038 MK-014 MS-049
