7. Record of Self-diagnosis check
Page 2 Address B0 to C6
Address Self-diagnosis code
B0 “Repaired by” code (Occurred 1st time) *1
B1 “Block function” code (Occurred 1st time)
B2 “Detailed” code (Occurred 1st time)
B4 “Repaired by” code (Occurred 2nd time) *1
B5 “Block function” code (Occurred 2nd time)
B6 “Detailed” code (Occurred 2nd time)
B8 “Repaired by” code (Occurred 3rd time) *1
B9 “Block function” code (Occurred 3rd time)
BA “Detailed” code (Occurred 3rd time)
BC “Repaired by” code (Occurred 4th time) *1
BD “Block function” code (Occurred 4th time)
BE “Detailed” code (Occurred 4th time)
C0 “Repaired by” code (Occurred 5th time) *1
C1 “Block function” code (Occurred 5th time)
C2 “Detailed” code (Occurred 5th time)
C4 “Repaired by” code (Occurred the last time) *1
C5 “Block function” code (Occurred the last time)
C6 “Detailed” code (Occurred the last time)
*1 : “01” → “C”, “03” → “E”
Using method:
1) The past self-diagnosis codes are displayed at page: 2, addresses: BC to C6. Refer to “SELF-DIAGNOSIS FUNCTION” for detail of
the self-diagnosis code.
Note: This data will be erased (reset) when the cabinet (R) assy (CK-093 board) is removed.
