5-13
1-2-3. INITIALIZATION OF E, F PAGE DATA
1. Initializing the E, F Page Data
Note1: If “Initializing the E, F Page Data” is performed, all data of the E
page and F page will be initialized. (It is impossible to initialize a
single page.)
Note2: If the E, F page data has been initialized, following adjustments
need to be performed again.
1) Modification of E, F page data
2) Camera system adjustments
Adjustment Page F
Adjustment Address 10 to FF
Adjustment Page E
Adjustment Address 00 to F4 (Note3)
00 to F6 (Note4)
00 to F7 (Note5)
Note3: Camera microprocessor ver. 1.0
Note4: Camera microprocessor ver. 2.0
Note5: Camera microprocessor ver. 3.0
Switch setting:
POWER.................................................................. CAMERA
Initializing Method:
Order Page
Address
Data Procedure
1 0 01 01 Set the data.
2 6 01 Set the following data, and press
PAUSE button.
2D: DCR-VX2000 (NTSC)
2F : DCR-VX2000E (PAL)
3 6 03 01 Set the data, and press PAUSE
button.
4 6 02 Check that the data changes to
“01”.
5 Perform “Modification of E, F
Page Data”.
2. Modification of E, F Page Data
If the E, F page data has been initialized, change the data of the
“Fixed data-2” address shown in the following table by manual input.
Modifying Method:
1) Before changing the data, select page: 0, address: 01, and set
data: 01.
2) New data for changing are not shown in the tables because
they are different in destination. When changing the data, copy
the data built in the same model.
Note: If copy the data built in the different model, the camcorder may
not operate.
3) When changing the data, press the PAUSE button of the
adjustment remote commander each time when setting new
data to write the data in the non-volatile memory.
4) Check that the data of adjustment addresses is the initial value.
If not, change the data to the initial value.
Processing after Completing Modification of E, F Page data
1) Select page: 0, address: 01, and set data: 00.
2) Turn off the power and turn on again.
3. Modification of E Page Data
When replacing the camera microprocessor (VC-242 board IC802),
change the data shown in the following table by manual input.
Version check of the camera microprocessor:
Order Page
Address
Data Procedure
1 6 FF The data shows the version of
the camera microprocessor.
01: Ver. 1.0
02: Ver. 2.0
03: Ver. 3.0
Modifying Method:
• When replaced with the camera microprocessor ver. 2.0.
Order Page
Address
Data Procedure
1 0 01 01 Set the data.
2 E F5 8B Set the data, and press PAUSE
button.
3 E F6 D0 Set the data, and press PAUSE
button.
4 0 01 00 Set the data.
5 Turn off the power and turn on
again.
• When replaced with the camera microprocessor ver. 3.0.
Order Page
Address
Data Procedure
1 0 01 01 Set the data.
2 E F5 8B Set the data, and press PAUSE
button.
3 E F6 D0 Set the data, and press PAUSE
button.
4 E F7 25 Set the data, and press PAUSE
button.
5 0 01 00 Set the data.
6 Turn off the power and turn on
again.
To Next Page
