Sony DCR-VX2000 - Waveforms

4-109
DCR-VX2000/VX2000E
WAVEFORMS
CD-254, PD-126, LB-065
4-3. WAVEFORMS
PD-126 BOARD
REC/PB
1 IC2101 rh
500mVp-p
H
8 IC2103 wh
2.9Vp-p
56 nsec
9 IC2103 rk
2.9Vp-p
V
2 IC2101 rj
440mVp-p
H
3 IC2101 rk
420mVp-p
H
4 IC2101 w;
8.0Vp-p
2H
5 IC2101 ws
8.0Vp-p
2H
6 IC2101 wf
8.0Vp-p
2H
7 IC2103 1
2.8Vp-p
H
8Vp-p
H
H
0.2Vp-p
H
0.3Vp-p
H
0.4Vp-p
74 nsec
3.4Vp-p
74 nsec
3.4Vp-p
34msec
19V
17msec
19.5Vp-p
CD-254 BOARD
REC
1 IC100, 101, 102 1,2
2 IC100, 101, 102 3,4
3 IC100, 101, 102 qa
4 IC100, 101, 102 qf
5 IC100, 101, 102 qg,qh
6 IC101 8
7 IC102 8
8 IC100 8
LB-065 BOARD
REC/PB
1 IC200 4
4.6Vp-p
H
