4-110
DCR-VX2000/VX2000E
WAVEFORMS
HL-011, DD-138
DD-138 BOARD (1/2)
CAMERA REC
2 IC300 t;

3 IC300 td

1 IC300 rj
5.2Vp-p
2.5 µsec
5.2Vp-p
5.2Vp-p
2.5 µsec
5.2Vp-p
2.5 µsec
2.5 µsec
4 IC300 th
5 IC300 tk
5.2Vp-p
2.5 µsec
8 IC300 3
1.4Vp-p
2.5 µsec
7 IC300 yf
5.2Vp-p
2.5 µsec
6 IC300 ya
5.2Vp-p
2.5 µsec
HL-011 BOARD
REC/PB
1 IC1701 2
3.0Vp-p
38 µsec
