Sony DCR-VX2000 - Center Frame Section

6-9
6-1-9. CENTER FRAME SECTION
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
not supplied
not supplied
402
403
404
405
406
407
407
414
407
408
409
410
401
411
407
413
407
412
412
Lens block section
(See page 6-10)
401 X-3950-681-1 FRAME ASSY, CENTER
402 3-060-620-01 BUTTON, IP
403 3-060-621-01 ESCUTCHEON
404 3-060-622-01 KNOB, MF
405 3-060-619-01 KNOB, ND
406 3-060-623-01 COVER, BUTTON
407 3-053-121-11 BOLT (M2), SPRING
408 1-678-056-21 FP-188 FLEXIBLE BOARD
409 3-060-685-01 COVER, CCD
410 3-948-339-61 TAPPING
411 3-053-121-21 BOLT (M2), SPRING
412 3-060-795-01 TAPE, HARNESS FIXED
413 1-960-654-11 HARNESS, CJ-064
414 3-968-729-91 SCREW(M2), LOCK ACE, P2
