6-16
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C375 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C376 1-135-212-21 TANTAL. CHIP 2.2uF 20% 35V
C450 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
< CONNECTOR >
CN300 1-573-290-21 PIN, CONNECTOR (1.5MM) (SMD)4P
CN301 1-691-550-11 PIN, CONNECTOR (1.5MM)(SMD) 3P
CN450 1-778-084-11 CONNECTOR, BOARD TO BOARD 60P
< DIODE >
D300 8-719-158-49 DIODE MA8120-TX
D301 8-719-073-03 DIODE MA8082-(K8).S0
D302 8-719-073-03 DIODE MA8082-(K8).S0
D303 8-719-073-03 DIODE MA8082-(K8).S0
D304 8-719-056-48 DIODE 1SS388(TPL3)
D305 8-719-058-24 DIODE RB501V-40TE-17
D306 8-719-058-24 DIODE RB501V-40TE-17
D307 8-719-058-24 DIODE RB501V-40TE-17
D308 8-719-056-48 DIODE 1SS388(TPL3)
D311 8-719-056-48 DIODE 1SS388(TPL3)
D312 8-719-056-48 DIODE 1SS388(TPL3)
D313 8-719-056-48 DIODE 1SS388(TPL3)
D314 8-719-056-23 DIODE MA2S111-(K8).SO
D315 8-719-075-12 DIODE MA3XD21001S0
D316 8-719-056-23 DIODE MA2S111-(K8).SO
< FUSE >
0F300 1-576-286-21 FUSE, MICRO(1.4A)
0F301 1-576-286-21 FUSE, MICRO(1.4A)
0F302 1-576-286-21 FUSE, MICRO(1.4A)
0F303 1-576-286-21 FUSE, MICRO(1.4A)
0F304 1-576-286-21 FUSE, MICRO(1.4A)
0F305 1-576-286-21 FUSE, MICRO(1.4A)
< IC >
IC300 8-759-491-09 IC MB4488PFV-G-BND-ER
IC301 8-759-075-66 IC TA75S01F(TE85R)
< COIL >
L300 1-416-669-11 INDUCTOR 22uH
L301 1-416-670-11 INDUCTOR 33uH
L302 1-416-669-11 INDUCTOR 22uH
L303 1-416-669-11 INDUCTOR 22uH
L304 1-416-669-11 INDUCTOR 22uH
L305 1-416-669-11 INDUCTOR 22uH
L306 1-412-056-11 INDUCTOR 4.7uH
L307 1-414-770-91 INDUCTOR CHIP 4.7uH
L308 1-412-056-11 INDUCTOR 4.7uH
L309 1-414-400-11 INDUCTOR 22uH
L310 1-414-770-91 INDUCTOR CHIP 4.7uH
L311 1-414-770-91 INDUCTOR CHIP 4.7uH
L312 1-412-056-11 INDUCTOR 4.7uH
L313 1-414-770-91 INDUCTOR CHIP 4.7uH
L314 1-414-770-91 INDUCTOR CHIP 4.7uH
L315 1-414-394-11 INDUCTOR 2.2uH
L316 1-414-770-91 INDUCTOR CHIP 4.7uH
L317 1-469-058-11 INDUCTOR CHIP 22uH
L318 1-469-058-11 INDUCTOR CHIP 22uH
L319 1-414-770-91 INDUCTOR CHIP 4.7uH
L451 1-414-770-91 INDUCTOR CHIP 4.7uH
< TRANSISTOR >
Q300 8-729-047-68 TRANSISTOR SSM3K03FE(TPL3)
Q301 8-729-046-77 TRANSISTOR SI4963DY-T1
Q302 8-729-804-41 TRANSISTOR 2SB1122-ST-TD
Q303 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q304 8-729-047-68 TRANSISTOR SSM3K03FE(TPL3)
Q305 8-729-050-24 TRANSISTOR MCH6202-TL
Q306 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q307 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q308 8-729-043-60 TRANSISTOR CPH6102-TL
Q309 8-729-046-98 TRANSISTOR CPH6702-TL
Q310 8-729-046-98 TRANSISTOR CPH6702-TL
Q311 8-729-046-98 TRANSISTOR CPH6702-TL
Q312 8-729-046-98 TRANSISTOR CPH6702-TL
Q313 8-729-046-98 TRANSISTOR CPH6702-TL
Q314 8-729-046-98 TRANSISTOR CPH6702-TL
Q315 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q316 8-729-017-61 TRANSISTOR 2SB1581-T1
Q317 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q318 8-729-044-58 TRANSISTOR SI2304DS-T1
Q319 8-729-044-58 TRANSISTOR SI2304DS-T1
Q320 8-729-044-58 TRANSISTOR SI2304DS-T1
Q321 8-729-044-58 TRANSISTOR SI2304DS-T1
Q322 8-729-044-58 TRANSISTOR SI2304DS-T1
Q323 8-729-044-58 TRANSISTOR SI2304DS-T1
Q324 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q325 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q327 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q329 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q331 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q332 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q333 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q334 8-729-049-25 TRANSISTOR 2SC5376F-B(TPL3)
Q335 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q337 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q338 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q339 8-729-042-56 TRANSISTOR MGSF3455VT1
Q340 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q341 8-729-049-91 TRANSISTOR 2SA2018H-T2L
Q344 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q345 8-729-034-59 TRANSISTOR 2SA1745-6.7-TL
Q348 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q349 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q351 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
< RESISTOR >
R300 1-218-953-11 RES-CHIP 1K 5% 1/16W
R301 1-216-296-91 SHORT 0
R302 1-216-296-91 SHORT 0
R303 1-218-985-11 RES-CHIP 470K 5% 1/16W
R304 1-218-989-11 RES-CHIP 1M 5% 1/16W
R305 1-218-969-11 RES-CHIP 22K 5% 1/16W
R306 1-216-150-91 RES-CHIP 10 5% 1/8W
R307 1-218-969-11 RES-CHIP 22K 5% 1/16W
R308 1-218-969-11 RES-CHIP 22K 5% 1/16W
R309 1-218-969-11 RES-CHIP 22K 5% 1/16W
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
DD-138
