Table of Contents
Overview......................................................................... 12
Components of the DSBK-190 .....................................13
Installation...................................................................... 14
The DSBK-190 i.LINK/DV Input/Output Board is an optional
board for the DSR-2000/2000P Sony Digital Videocassette
Recorder. Installing this board in a DSR-2000/2000P allows
two DSR-2000/2000P units to be connected with an i.LINK/
DV
1)
cable to form a cut editing system. The board also allows
the connection of a Sony consumer DV camera for direct
recording and editing.
Refer to the DSR-2000/2000P Operating Instructions for
information on connecting and operating the DSR-2000/2000P
with the DSBK-190 installed.
Overview
1)
is a trademark of Sony Corporation, and indicates technology
complying with the IEEE1394-1995 specification and extensions
thereof.
..........................................................................................................................
13
Components of the DSBK-190
The DSBK-190 consists of the following items.
Connector panel
IF-763 board
Harness
6-pin cable (3.5 m (11 feet))
Screw (M3 × 6,
silver-colored)
Washer
6-pin/4-pin cable
(1 m (3 feet))
1-2. DSBK-190
