Sony HCD-HPX7 - Tuner (FM;AM), DC Fan

13
HCD-HPX7
3-8. TUNER (FM/AM), DC FAN
qf two screws (FAN)
1 two screws
(BVTP3 × 8 )
2 screw
(BVTP3 × 8 )
3 two screws
(BVTP3 × 8 )
4 three screws
(BVTP3 × 8 )
0 two screws
(BVTP3 × 10
)
8 connector (CN313)
6 claw
qg DC fan
qa tuner (FM/AM)
qd heat cover plate
5 claw
9 w ire (flat type) 11p or 15p(CN305)
qs w ire (flat type) 11p or 15p
7 heat sink cover
heat sink cover
MAIN board
