Sony HCD-HPX7 - CD MECHANISM DECK SECTION-9 (CDM82 A)

95
HCD-HPX7
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
8-13. CD MECHANISM DECK SECTION-9
(CDM82A)
1101
1121
1102
1102
1103
1104
1107
1108
1109
1110
1111
1112
1103
1120
1114
1117
1119
1116
1113
1105
1115
1105
1106
1106
1118
1101 4-245-627-01 WASHER (6-2.7-0.4)
1102 4-245-637-01 ROLLER, RUBBER
1103 4-245-649-01 GEAR (IDL-I)
1104 4-245-657-01 LEVER (LOADING-R)
1105 4-245-647-01 GEAR (IDL-G)
1106 4-245-648-01 GEAR (IDL-H)
1107 4-245-655-01 CHASSIS (TOP)
1108 4-245-631-01 SPT-T (LOADING-R)
1109 4-245-650-01 GEAR (IDL-J)
1110 4-245-651-01 GEAR (IDL-L)
1111 4-245-640-01 GEAR (CAP)
1112 1-452-925-21 MAGNET ASSY
1113 4-245-638-01 LEVER (CL UP1)
1114 4-985-672-01 SCREW (+PTPWHM2.6), FLOATING
1115 4-245-636-01 SPR-T CL DOWN
1116 4-245-658-01 LEVER (DISC STOP)
1117 4-245-659-01 LEVER (DISC SENSOR)
1118 4-245-632-01 SPR-T (LOADING-L)
1119 X-2021-532-1 CLAMPER 213 ASSY
1120 4-245-656-01 LEVER (LOADING-L)
1121 4-253-747-01 STOPPER, IDL I
