37
HCD-HPX7
3-43. SPR-E (TAKO-BACK)
5
SPR-E (tako-back)
4
tension spring (lower
)
1
four screws (2
×
5)
3
four
rubber rollers
2
four parasols
two claws
two claws
rubber roller
parasol
