Sony HCD-HPX7 - DISASSEMBLY; DISASSEMBLY FLOW-1

7
HCD-HPX7
SECTION 3
DISASSEMBLY
•This is can be disassemble according to the following sequence.
3-6.FRONT PANEL SECTION
(Page 12)
3-8.TUNER (FM/AM),
DC FAN
(Page 13)
3-9.MAIN BOARD
(Page 14)
3-10.REAR PANEL SECTION
(Page 14)
3-5.MECHANICAL DECK
(Page 11)
3-3.OPTICAL PICK-UP
BLOCK
(Page 9)
3-11.AMP BOARD,
SWITCHING REGULATOR
(Page 15)
3-12.POWER BOARD
(Page 15)
to DISASSEMBLY FLOW-2
3-13.CD MECHANISM DECK
(CDM82A)
(Page 16)
3-7.PANEL (1), (2) BOARD
HEADPHONE BOARD
(Page 12)
3-4.SIDE PLATE (L) (R),
TOP PANEL SECTION
(Page 10)
SET
3-1. DISASSEMBLY FLOW-1
