Sony HCD-HPX7 - DRIVER BOARD

33
HCD-HPX7
3-35. DISC STOP LEVER
3-36. DRIVER BOARD
chassis (top)
hole
Install the disc stop lever so that the both holes
are aligned.
hole
1 gear (cap)
3 two claws
5 two hooks
6 disc stop lever
disc stop lever
4 disc sensor lever
2 gear (IDL L)
PRECAUTION DURING DISC STOP LEVER INSTALLATION
3 Remove soldering
from the two points.
2 three screws
(BVTP2.6
× 8)
5 DRIVER boar
d
4 motor (pulley) assy
(LOD)
1 belt (MOT)
