Sony HCD-HPX7 - Gear (IDL-B); Gear (IDL-C)

36
HCD-HPX7
3-41. GEAR (IDL-B)
3 gear pulley
2 claw
9 DIR lever
5 gear (IDL-A)
q; gear (IDL B long)
1 DIR spring
8 stopper
6 Loosen the screw.
7 Hold the Release lever
and change the direction.
4 gear (cap)
3-42. GEAR (IDL-C)
6 claw
1 gear (IDL-F)
5 gear loading lever
2 two claws
4 three hooks
3 gear (IDL-D)
7 gear (IDL-C)
