98
HCD-HPX7
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
•Abbreviation
AUS: Australian model
CND : Canadian model
E3 : 240 V AC area in E model
KR : Korean model
MX : Mexican model
TW : Taiwan model
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
AMP
A-1061-313-A AMP BOARD, COMPLETE (CND)
A-1061-433-A AMP BOARD, COMPLETE (AEP, UK)
A-1061-758-A AMP BOARD, COMPLETE
(EXCEPT CND, AEP, UK)
********************
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C503 1-126-967-11 ELECT 47uF 20% 50V
C504 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C505 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C506 1-126-957-11 ELECT 0.22uF 20% 50V
C507 1-130-495-00 MYLAR 0.1uF 5% 50V
C551 1-126-964-11 ELECT 10uF 20% 50V
C552 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C553 1-126-967-11 ELECT 47uF 20% 50V
C554 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C555 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C556 1-126-957-11 ELECT 0.22uF 20% 50V
C557 1-130-495-00 MYLAR 0.1uF 5% 50V
C603 1-162-294-31 CERAMIC 0.001uF 10% 50V
C604 1-126-964-11 ELECT 10uF 20% 50V
C605 1-104-658-91 ELECT 100uF 20% 10V
C606 1-162-294-31 CERAMIC 0.001uF 10% 50V
C607 1-126-964-11 ELECT 10uF 20% 50V
C608 1-104-658-91 ELECT 100uF 20% 10V
C609 1-126-961-11 ELECT 2.2uF 20% 50V
C610 1-126-965-91 ELECT 22uF 20% 50V
C611 1-126-965-91 ELECT 22uF 20% 50V
C612 1-126-969-11 ELECT 220uF 20% 50V
C613 1-126-964-11 ELECT 10uF 20% 50V
C614 1-128-550-11 ELECT 2200uF 20% 50V
C615 1-128-550-11 ELECT 2200uF 20% 50V
C616 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C617 1-130-471-00 MYLAR 0.001uF 5% 50V
< CONNECTOR >
CN601 1-568-828-11 CONNECTOR, FFC 9P
* CN602 1-564-510-11 PLUG, CONNECTOR 7P
CN603 1-564-509-11 PLUG, CONNECTOR 6P
CN604 1-564-506-11 PLUG, CONNECTOR 3P
* CN605 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< CONNECTOR >
CNJ991 1-815-443-11 PIN, CONNECTOR (PWB) 2P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-77
D551 8-719-991-33 DIODE 1SS133T-77
D603 8-719-991-33 DIODE 1SS133T-77
D607 8-719-109-85 DIODE MTZJ-T-77-5.1B
D608 8-719-991-33 DIODE 1SS133T-77
D609 8-719-991-33 DIODE 1SS133T-77
D610 8-719-991-33 DIODE 1SS133T-77
D611 8-719-991-33 DIODE 1SS133T-77
D612 8-719-991-33 DIODE 1SS133T-77
< IC >
IC601 6-705-620-01 IC STK433-060 (EXCEPT AEP, UK)
IC601 6-705-621-01 IC STK433-070 (AEP, UK)
IC602 6-703-610-01 IC RT8H015C-T112-1
< TRANSISTOR >
Q501 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q502 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q551 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q552 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q601 8-729-038-54 TRANSISTOR KRA102S
Q602 8-729-038-54 TRANSISTOR KRA102S
Q603 8-729-038-67 TRANSISTOR KRC102S
Q604 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q605 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q606 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q607 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q608 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q609 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q610 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q611 8-729-016-42 TRANSISTOR KTC3199GR-TP
< RESISTOR >
R501 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R502 1-216-842-11 METAL CHIP 56K 5% 1/10W
R503 1-216-821-11 METAL CHIP 1K 5% 1/10W
R505 1-216-864-11 SHORT CHIP 0
R506 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(AEP, UK)
To Next Page
