Sony HCD-HPX7 - Assembling of the Stocker Section

41
HCD-HPX7
6 stocker (1) assy
2 stocker (1) assy
3 stocker (2) assy
7 stocker (2) assy
5 tow claws
4 tow dowels
8 stocker (3) assy
9 stocker (4) assy
0 stocker (5) assy
UPPER
SIDE
1 Repeat the steps 4 to 6 , when installing the part
(2), (3), (4) and (5) of the stocker assy.
1 Check the number on each stocker assy,
before assembling all the assys.
4-2. ASSEMBLING OF THE STOCKER SECTION
