Sony HCD-HPX7 - ARM SECTION

18
HCD-HPX7
3-16. ARM SECTION
B
A
1 T urn over the pulley (LOD motor)
in the direction of the arrow
A .
2 Slide the arm section in the
direction of the arrow B .
4 Push this portion with a finger
in the direction of the arrow C .
3 claw
6 arm section
5 Remove the arm section
in the direction of the arrow D .
C
D
1 gear (joint op),
two shaft (shaft) stocks
8 gear (joint op), two shaft (shaft) stocks
2 loosen two
screws
4 two claws 5 arm section
3 turn over the
gear (swing)
in the direction
of the arrow.
7 two
screws
6 Push this portion with a finger
in the direction of the arrow C .
gear (swing)
PRECAUTION DURING ARM SECTION
INSTALLATION
