6. Remove the supplied nut with the new coaxial connector converter (BNC type) and discard the supplied star washer.
7. Install the removed parts by reversing the steps of removal.
Note
• Before installing the supplied nut, apply locking compound.
• Install the BNC coaxial fixed washers in the orientation shown below.
Tip
• The size of a grain of rice means about 20 μL.
• Tightening torque: 1.4 ±0.02 N·m
Supplied nut
Supplied star washer
Coaxial connector converter (BNC type)
Locking compound (1401B)
One rice grain size
BNC coaxial fixed washers
Supplied nuts
