– 36 –
KDF-E42A10/E50A10
K RM-YD003 RM-YD003
7. ELECTRICAL PARTS LIST
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be anticipated
when ordering these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
• RESISTORS
All resistors are in ohms
F : nonflammable
• CAPACITORS
PF : µµF
• There are some cases the reference
number on one board overlaps on the
other board. Therefore, when ordering
parts by the reference number, please
include the board name.
REF. NO. PART NO. DESCRIPTION REMARK
––––––– –––––––– ––––––––––– –––––––
REF. NO. PART NO. DESCRIPTION REMARK
––––––– –––––––– ––––––––––– –––––––
AGU
A-1129-346-A AGU BOARD, COMPLETE
************************
* 4-042-408-02 PIN(45), WIRE
< CAPACITOR >
C8004 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C8005 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8006 1-128-993-21 ELECT CHIP 22µF 20% 10V
C8007 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8008 1-128-993-21 ELECT CHIP 22µF 20% 10V
C8009 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8010 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8011 1-128-993-21 ELECT CHIP 22µF 20% 10V
C8012 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8013 1-128-993-21 ELECT CHIP 22µF 20% 10V
C8014 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8015 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8016 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8017 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8018 1-128-993-21 ELECT CHIP 22µF 20% 10V
C8019 1-128-993-21 ELECT CHIP 22µF 20% 10V
C8020 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8021 1-117-681-11 ELECT CHIP 100µF 20% 16V
C8022 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8023 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C8024 1-162-969-11 CERAMIC CHIP 0.0068µF 10% 25V
C8025 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8026 1-110-563-11 CERAMIC CHIP 0.068µF 10% 16V
C8027 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8028 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C8029 1-162-969-11 CERAMIC CHIP 0.0068µF 10% 25V
C8030 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8031 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8032 1-110-563-11 CERAMIC CHIP 0.068µF 10% 16V
C8033 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C8034 1-162-969-11 CERAMIC CHIP 0.0068µF 10% 25V
C8035 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8036 1-110-563-11 CERAMIC CHIP 0.068µF 10% 16V
C8037 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8038 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8039 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8040 1-117-681-11 ELECT CHIP 100µF 20% 16V
C8041 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C8042 1-162-926-11 CERAMIC CHIP 82pF 5% 50V
C8043 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8044 1-162-916-11 CERAMIC CHIP 12pF 5% 50V
C8045 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8046 1-162-916-11 CERAMIC CHIP 12pF 5% 50V
C8047 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8048 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C8049 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C8050 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8051 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8052 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8053 1-162-918-11 CERAMIC CHIP 18pF 5% 50V
C8054 1-162-917-11 CERAMIC CHIP 15pF 5% 50V
C8057 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8058 1-165-908-11 CERAMIC CHIP 1µF 10% 10V
C8066 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8067 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8068 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8073 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8074 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8075 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8076 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8077 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8078 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8079 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8080 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8081 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8082 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8083 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8084 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8085 1-117-681-11 ELECT CHIP 100µF 20% 16V
C8086 1-117-681-11 ELECT CHIP 100µF 20% 16V
C8087 1-117-681-11 ELECT CHIP 100µF 20% 16V
C8088 1-117-681-11 ELECT CHIP 100µF 20% 16V
C8089 1-117-681-11 ELECT CHIP 100µF 20% 16V
C8090 1-165-908-11 CERAMIC CHIP 1µF 10% 10V
C8091 1-165-908-11 CERAMIC CHIP 1µF 10% 10V
C8092 1-128-991-21 ELECT CHIP 10µF 20% 50V
C8093 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8094 1-128-993-21 ELECT CHIP 22µF 20% 10V
C8101 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8102 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8103 1-117-681-11 ELECT CHIP 100µF 20% 16V
C8109 1-117-681-11 ELECT CHIP 100µF 20% 16V
C8110 1-117-681-11 ELECT CHIP 100µF 20% 16V
C8111 1-128-991-21 ELECT CHIP 10µF 20% 50V
C8112 1-128-991-21 ELECT CHIP 10µF 20% 50V
C8113 1-162-962-11 CERAMIC CHIP 470pF 10% 50V
C8114 1-162-962-11 CERAMIC CHIP 470pF 10% 50V
C8115 1-128-394-11 ELECT CHIP 220µF 20% 10V
C8116 1-127-573-11 CERAMIC CHIP 1µF 10% 16V
C8117 1-127-573-11 CERAMIC CHIP 1µF 10% 16V
C8118 1-126-395-11 ELECT CHIP 22µF 20% 16V
When indicating parts by reference number,
please include the board name.
