Sony KDF-E50A10 - Remove Stay (L), Side; Pull out some Blocks (1); Pull out some Blocks (2); Pull out some Blocks (3)

– 26 –
KDF-E42A10/E50A10
K RM-YD003 RM-YD003
2-24-7. Remove Stay (L), Side
2-24-8. Pull Out Some Blocks (1)
Take off 4 screws, and then remove 2 "Stay (L), Side".
Take off 4 screws.
2-24-9. Pull Out Some Blocks (2)
2-24-10. Pull Out Some Blocks (3)
Take off 5 screws.
Pull out "B block", "Chassis block", and "Duct (R), Main"
a little bit.
2-24-11. Pull Out Some Blocks (4)
Unlock "Holder, Wire" as shown below.
