Sony KDF-E50A10 - Main Duct (R); (Without Main Duct (R)); Fan (Sirocco); Speaker Grill Block Assembly

– 23 –
KDF-E42A10/E50A10
K RM-YD003 RM-YD003
2-16. MAIN DUCT (R)
2 Pull out duct block assembly
1 Screw (+BVTP 4x16)
2-17. DUCT BLOCK ASSEMBLY
(WITHOUT MAIN DUCT (R))
2 Pull out main duct (R)
1 2 screws (+BVTP 4x16)
2-18. D.C. FAN (SIROCCO)
1 2 claws
Lamp duct cover
4 Remove SIROCCO
fan cover upward
3 Screw (+BVTP 4x16)
2
Speaker grill block assembly
2-19. SPEAKER GRILL BLOCK ASSEMBLY
5
5
5
R
e
m
o
v
e
D.
C
. f
a
n
(
sirrocco
)
u
p
ward
1 2 screws
(+BVTP 4x16)
