Sony KDF-E50A10 - Pull out some Blocks (5); Pull out some Blocks (6); Pull out some Blocks (7)

– 27 –
KDF-E42A10/E50A10
K RM-YD003 RM-YD003
2-24-12. Pull Out Some Blocks (5)
Take off 1 screw.
2-24-13. Pull Out Some Blocks (6)
Loose 1 special screw. (This screw can not be taken off.)
2-24-14. Pull Out Some Blocks (7)
Take off 1 screw.
3 screws
1 screw
< F >
F
Optics unit block
1 special screw
< G >
G
Optics unit block
1 special screw
< H >
H
