– 65 –
REF. NO. PART NO. DESCRIPTION REMARK
––––––– –––––––– ––––––––––– –––––––
REF. NO. PART NO. DESCRIPTION REMARK
––––––– –––––––– ––––––––––– –––––––
KDF-E42A10/E50A10
K RM-YD003 RM-YD003
R6246 0 1-219-568-91 METAL 8.2M 5% 1/2W
R6248 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R6249 1-219-759-11 METAL 1M 5% 1/2W
R6250 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R6251 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R6252 1-216-837-11 METAL CHIP 22K 5% 1/10W
R6253 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6254 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6255 1-216-344-00 METAL OXIDE 0.39 5% 1W
R6257 1-216-349-00 METAL OXIDE 1 5% 1W
R6259 1-244-207-11 WIREWOUND 3.3 5% 10W
R6261 1-260-328-11 CARBON 1K 5% 1/2W
R6262 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R6263 1-249-389-11 CARBON 4.7 5% 1/4W
R6267 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R6268 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6273 1-249-389-11 CARBON 4.7 5% 1/4W
R6277 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6278 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R6279 1-216-845-11 METAL CHIP 100K 5% 1/10W
R6280 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6281 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6283 1-243-979-71 METAL OXIDE 0.1 5% 2W
R6284 1-216-864-11 SHORT CHIP 0
R6285 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R6286 1-216-834-11 METAL CHIP 12K 5% 1/10W
R6287 1-218-720-11 METAL CHIP 15K 0.5% 1/10W
R6288 1-218-708-11 METAL CHIP 4.7K 0.5% 1/10W
R6291 1-216-864-11 SHORT CHIP 0
R6296 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6297 1-216-801-11 METAL CHIP 22 5% 1/10W
R6300 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6301 1-216-864-11 SHORT CHIP 0
R6302 1-216-845-11 METAL CHIP 100K 5% 1/10W
R6339 1-216-864-11 SHORT CHIP 0
< RELAY >
RY600101-755-388-11 RELAY (AC POWER)
RY600201-755-388-11 RELAY (AC POWER)
< SPARK GAP >
SG6000 1-576-487-11 ELEMENT, SPARK
< TRANSFORMER >
T6000 0 1-443-747-11 TRANSFORMER (PIT)
T6004 0 1-443-748-11 TRANSFORMER (SRT)
< VARISTOR >
VD600001-804-992-21 VARISTOR
VD600101-804-991-21 VARISTOR
VD600301-804-991-21 VARISTOR
***************************************************************
A-1103-762-A HA BOARD, COMPLETE
**********************
< CAPACITOR >
C7000 1-100-597-91 CERAMIC CHIP 0.1UF 10% 25V
< CONNECTOR >
CN7000 1-819-445-11 HEADER ASSEMBLY FOR PWB 3P
< RESISTOR >
R7001 1-218-676-11 METAL CHIP 220 0.5% 1/10W
R7002 1-218-684-11 METAL CHIP 470 0.5% 1/10W
R7003 1-218-691-11 METAL CHIP 910 0.5% 1/10W
R7004 1-218-698-11 METAL CHIP 1.8K 0.5% 1/10W
R7005 1-218-706-11 METAL CHIP 3.9K 0.5% 1/10W
< SWITCH >
S7000 1-692-431-21 SWITCH, TACTILE
S7001 1-692-431-21 SWITCH, TACTILE
S7002 1-692-431-21 SWITCH, TACTILE
S7003 1-692-431-21 SWITCH, TACTILE
S7004 1-692-431-21 SWITCH, TACTILE
S7005 1-692-431-21 SWITCH, TACTILE
***************************************************************
A-1103-763-A HB BOARD, COMPLETE
**********************
< CAPACITOR >
C7020 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C7021 1-126-964-11 ELECT 10UF 20% 50V
C7022 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C7023 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C7024 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C7025 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C7026 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C7027 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C7028 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C7029 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C7030 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C7031 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C7032 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
< DIODE >
D7022 6-500-861-01 DIODE SML-020MVT-T86
D7023 8-719-064-07 DIODE SML-310LTT86
D7024 6-500-861-01 DIODE SML-020MVT-T86
< IC >
IC7020 6-600-210-01 IC RPM7240-H8
IC7021 6-707-223-01 IC LM75BIM-5/NOPB
< TRANSISTOR >
Q7020 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q7021 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q7022 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q7023 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q7024 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R7020 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R7021 1-216-805-11 METAL CHIP 47 5% 1/10W
Les composants identifies par
une trame et une marque
!
sont critiques pour la securite.
Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark ! are criti-
cal for safety.
Replace only with part number
specified.
GT HA HB
