Sony KDF-E50A10 - Page 211

– 39 –
REF. NO. PART NO. DESCRIPTION REMARK
––––––– –––––––– ––––––––––– –––––––
REF. NO. PART NO. DESCRIPTION REMARK
––––––– –––––––– ––––––––––– –––––––
KDF-E42A10/E50A10
K RM-YD003 RM-YD003
IC8703 6-706-740-01 IC BA00BC0WFP-E2
IC8704 8-752-072-94 IC CXA1875AM-T4
IC8705 8-759-278-58 IC NJM4558V-TE2
IC8706 6-703-225-01 IC S-80928CNMC-G8YT2G
IC8800 8-752-107-98 IC CXA2188Q-T4
IC8801 6-706-056-01 IC SN74LVC2GU04DCKR
IC8802 6-706-903-01 IC AK5357VT-E2
IC8803 6-706-902-01 IC CXD9835TNDBTR
IC8804 8-759-680-48 IC TC7WH157FK(TE85R)
IC8805 6-704-819-01 IC CS4335-KSZR
IC8806 8-759-278-58 IC NJM4558V-TE2
IC8807 6-704-819-01 IC CS4335-KSZR
< JACK >
J8400 1-780-271-11 S CONNECTOR BLOCK
J8401 1-819-357-11 PHONO JACK 10P
J8402 1-819-387-11 PHONO JACK 3P
J8403 1-780-272-11 TERMINAL BOARD
< COIL >
L8000 1-469-555-21 INDUCTOR 10µH
L8001 1-469-555-21 INDUCTOR 10µH
L8002 1-469-555-21 INDUCTOR 10µH
L8003 1-469-555-21 INDUCTOR 10µH
L8004 1-469-555-21 INDUCTOR 10µH
L8006 1-469-555-21 INDUCTOR 10µH
L8008 1-416-344-11 INDUCTOR 10µH
L8404 1-469-555-21 INDUCTOR 10µH
L8405 1-469-555-21 INDUCTOR 10µH
L8409 1-469-555-21 INDUCTOR 10µH
L8410 1-469-555-21 INDUCTOR 10µH
L8411 1-469-555-21 INDUCTOR 10µH
L8412 1-469-555-21 INDUCTOR 10µH
L8800 1-469-555-21 INDUCTOR 10µH
L8801 1-469-555-21 INDUCTOR 10µH
L8808 1-469-555-21 INDUCTOR 10µH
L8809 1-469-555-21 INDUCTOR 10µH
L8810 1-412-056-11 INDUCTOR 4.7µH
L8811 1-469-555-21 INDUCTOR 10µH
< TRANSISTOR >
Q8000 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8001 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8002 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8003 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8004 8-729-600-22 TRANSISTOR 2SA1235-F
Q8005 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8006 8-729-122-63 TRANSISTOR 2SA1226-E4
Q8008 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8009 8-729-600-22 TRANSISTOR 2SA1235-F
Q8010 8-729-600-22 TRANSISTOR 2SA1235-F
Q8011 8-729-600-22 TRANSISTOR 2SA1235-F
Q8012 8-729-600-22 TRANSISTOR 2SA1235-F
Q8013 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8014 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8015 8-729-600-22 TRANSISTOR 2SA1235-F
Q8017 8-729-600-22 TRANSISTOR 2SA1235-F
Q8018 8-729-600-22 TRANSISTOR 2SA1235-F
Q8019 8-729-028-28 TRANSISTOR 2SK2036(TE85L)
Q8020 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8021 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8022 8-729-028-28 TRANSISTOR 2SK2036(TE85L)
Q8023 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8024 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8025 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8026 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8027 8-729-600-22 TRANSISTOR 2SA1235-F
Q8028 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8029 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8030 6-550-832-01 TRANSISTOR SI2301BDS-T1
Q8031 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8032 8-729-600-22 TRANSISTOR 2SA1235-F
Q8033 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8034 8-729-600-22 TRANSISTOR 2SA1235-F
Q8035 8-729-600-22 TRANSISTOR 2SA1235-F
Q8036 8-729-122-63 TRANSISTOR 2SA1226-E4
Q8404 8-729-122-63 TRANSISTOR 2SA1226-E4
Q8405 8-729-122-63 TRANSISTOR 2SA1226-E4
Q8406 8-729-122-63 TRANSISTOR 2SA1226-E4
Q8407 8-729-117-73 TRANSISTOR 2SC4178-F14
Q8408 8-729-600-22 TRANSISTOR 2SA1235-F
Q8409 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8410 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8411 8-729-122-63 TRANSISTOR 2SA1226-E4
Q8412 8-729-122-63 TRANSISTOR 2SA1226-E4
Q8413 8-729-122-63 TRANSISTOR 2SA1226-E4
Q8415 8-729-600-22 TRANSISTOR 2SA1235-F
Q8418 8-729-600-22 TRANSISTOR 2SA1235-F
Q8419 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8420 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8600 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8700 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8701 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8702 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8703 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8704 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8705 8-729-600-22 TRANSISTOR 2SA1235-F
Q8706 8-729-600-22 TRANSISTOR 2SA1235-F
Q8707 8-729-600-22 TRANSISTOR 2SA1235-F
Q8708 8-729-600-22 TRANSISTOR 2SA1235-F
Q8709 8-729-600-22 TRANSISTOR 2SA1235-F
Q8710 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8711 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8712 8-729-600-22 TRANSISTOR 2SA1235-F
Q8713 8-729-600-22 TRANSISTOR 2SA1235-F
Q8714 8-729-600-22 TRANSISTOR 2SA1235-F
Q8715 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8716 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8717 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8718 8-729-600-22 TRANSISTOR 2SA1235-F
Q8800 8-729-600-22 TRANSISTOR 2SA1235-F
Q8801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R8000 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8001 1-216-841-11 METAL CHIP 47K 5% 1/10W
R8002 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8003 1-216-841-11 METAL CHIP 47K 5% 1/10W
R8005 1-216-864-11 SHORT CHIP 0
R8007 1-216-864-11 SHORT CHIP 0
R8010 1-216-809-11 METAL CHIP 100 5% 1/10W
R8011 1-216-809-11 METAL CHIP 100 5% 1/10W
R8014 1-216-864-11 SHORT CHIP 0
AGU
