– 63 –
KDF-E42A10/E50A10
K RM-YD003 RM-YD003
SECTION 6
ELECTRICAL PARTS LIST
When indicating parts by reference number,
please include the board name.
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be anticipated
when ordering these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
• RESISTORS
All resistors are in ohms
F : nonflammable
• CAPACITORS
PF : µµF
• There are some cases the reference
number on one board overlaps on the
other board. Therefore, when ordering
parts by the reference number, please
include the board name.
REF. NO. PART NO. DESCRIPTION REMARK
––––––– –––––––– ––––––––––– –––––––
REF. NO. PART NO. DESCRIPTION REMARK
––––––– –––––––– ––––––––––– –––––––
A-1113-732-A GT BOARD, COMPLETE
**********************
4-382-854-01 SCREW (M3X8), P, SW (+)
< CAPACITOR >
C6006 1-128-953-31 ELECT 470UF 20% 25V
C6007 1-128-953-31 ELECT 470UF 20% 25V
C6008 1-162-966-11 CERAMIC CHIP 0.0022UF 10% 50V
C6020 1-162-970-11 CERAMIC CHIP 0.01UF 10% 25V
C6021 1-126-967-11 ELECT 47UF 20% 50V
C6022 1-126-962-11 ELECT 3.3UF 20% 50V
C6023 1-162-970-11 CERAMIC CHIP 0.01UF 10% 25V
C6024 1-100-831-91 CERAMIC CHIP 0.001UF 2% 50V
C6026 1-126-964-11 ELECT 10UF 20% 50V
C6028 1-162-970-11 CERAMIC CHIP 0.01UF 10% 25V
C6029 1-136-497-81 FILM 0.1UF 5% 50V
C6030 1-126-947-11 ELECT 47UF 20% 35V
C6032 1-107-824-11 CERAMIC 220PF 5% 1KV
C6033 1-107-824-11 CERAMIC 220PF 5% 1KV
C6034 1-165-954-11 FILM 56000PF 3% 800V
C6035 1-126-969-11 ELECT 220UF 20% 50V
C6036 1-126-963-11 ELECT 4.7UF 20% 50V
C6039 1-126-963-11 ELECT 4.7UF 20% 50V
C6040 1-107-826-11 CERAMIC CHIP 0.1UF 10% 16V
C6041 1-162-970-11 CERAMIC CHIP 0.01UF 10% 25V
C6044 1-126-940-11 ELECT 330UF 20% 25V
C6045 0 1-165-530-31 MYLAR 0.47UF 10 0V
C6048 1-128-951-31 ELECT 2200UF 20% 16V
C6049 1-128-951-31 ELECT 2200UF 20% 16V
C6051 1-126-933-11 ELECT 100UF 20% 16V
C6052 1-137-190-91 FILM 0.22UF 5% 50V
C6053 1-126-947-11 ELECT 47UF 20% 35V
C6054 1-126-935-11 ELECT 470UF 20% 16V
C6055 1-126-947-11 ELECT 47UF 20% 35V
C6065 1-128-548-11 ELECT 4700UF 20% 25V
C6077 0 1-131-940-11 ELECT 1200UF 20% 250V
C6078 0 1-131-940-11 ELECT 1200UF 20% 250V
C6083 1-100-714-11 ELECT 100UF 20% 400V
C6084 1-100-714-11 ELECT 100UF 20% 400V
C6085 1-161-830-00 CERAMIC 0.0047UF 500V
C6272 0 1-161-964-91 CERAMIC 0.0047UF 250V
C6273 0 1-161-964-91 CERAMIC 0.0047UF 250V
C6274 0 1-165-530-31 MYLAR 0.47UF 10 0V
C6275 0 1-161-964-91 CERAMIC 0.0047UF 250V
C6276 1-161-964-91 CERAMIC 0.0047UF 250V
C6277 1-113-610-11 ELECT(BLOCK) 220UF 20% 250V
C6279 0 1-119-888-51 CERAMIC 2200PF 20% 250V
C6280 0 1-119-888-51 CERAMIC 2200PF 20% 250V
C6283 1-162-116-00 CERAMIC 680PF 10% 2KV
C6284 1-126-950-11 ELECT 330UF 20% 35V
C6285 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C6286 0 1-165-530-31 MYLAR 0.47UF 10 0V
C6289 1-137-353-11 MYLAR 0.047UF 5% 100V
C6290 1-137-365-11 MYLAR 0.0015UF 5% 50V
C6291 1-162-964-11 CERAMIC CHIP 0.001UF 10% 50V
C6292 1-126-934-11 ELECT 220UF 20% 16V
C6297 1-137-852-31 ELECT 3300UF 20% 16V
C6298 1-126-935-11 ELECT 470UF 20% 16V
C6299 1-164-227-11 CERAMIC CHIP 0.022UF 10% 25V
C6300 1-110-563-11 CERAMIC CHIP 0.068UF 10% 16V
C6304 1-126-947-11 ELECT 47UF 20% 35V
C6305 1-126-947-11 ELECT 47UF 20% 35V
C6323 1-126-935-11 ELECT 470UF 20% 16V
< CONNECTOR >
CN6002 1-794-502-11 PIN, CONNECTOR (B04B-PASK) 4P
CN6009 1-785-706-11 PIN, CONNECTOR (PC BOARD) 10P
CN601001-580-843-11 PIN, CONNECTOR (POWER)
CN6011 1-695-915-11 TAB (CONTACT)
CN6012 1-695-915-11 TAB (CONTACT)
CN6013 1-695-915-11 TAB (CONTACT)
CN6014 1-695-915-11 TAB (CONTACT)
CN6015 1-695-915-11 TAB (CONTACT)
CN6018 1-691-960-21 PIN, CONNECTOR (PC BOARD) 3P
CN6019 1-815-789-11 CONNECTOR, BOARD TO BOARD 50P
< DIODE >
D6000 0 8-719-510-53 DIODE D4SB60L
D6001 6-500-335-01 DIODE MC2838-T112-1
D6002 8-719-510-12 DIODE D10SC4M-F
D6011 8-719-979-64 DIODE UF4005/23
D6014 6-500-335-01 DIODE MC2838-T112-1
D6015 6-500-567-31 DIODE 10ERB20-TB3
D6018 8-719-028-45 DIODE D2L20U-TA
D6019 8-719-057-96 DIODE D10SC6M-4012
D6020 8-719-075-66 DIODE D5LC20U-4012
D6022 6-500-335-01 DIODE MC2838-T112-1
D6027 6-500-335-01 DIODE MC2838-T112-1
D6028 6-500-335-01 DIODE MC2838-T112-1
D6029 8-719-060-89 DIODE D4SBS6-F
D6032 6-501-223-01 DIODE S3G
D6033 6-501-223-01 DIODE S3G
GT
The components identified by shading and
mark
!
are critial for safety.
Replace only with part number specified.
Les composants identifies par une trame et une
marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specifie.
Electrical parts list of the specified boards for board
replacement service are not included in this
section.
See Appendix of this manual if you need them.
