– 70 –
REF. NO. PART NO. DESCRIPTION REMARK
––––––– –––––––– ––––––––––– –––––––
REF. NO. PART NO. DESCRIPTION REMARK
––––––– –––––––– ––––––––––– –––––––
KDF-E42A10/E50A10
K RM-YD003 RM-YD003
R7832 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R7833 1-216-864-11 SHORT CHIP 0
R7835 1-216-864-11 SHORT CHIP 0
R7839 1-216-864-11 SHORT CHIP 0
R7841 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7842 1-216-864-11 SHORT CHIP 0
R7844 1-216-809-11 METAL CHIP 100 5% 1/10W
R7845 1-216-821-11 METAL CHIP 1K 5% 1/10W
R7850 1-216-817-11 METAL CHIP 470 5% 1/10W
R7851 1-216-835-11 METAL CHIP 15K 5% 1/10W
R7852 1-216-817-11 METAL CHIP 470 5% 1/10W
R7853 1-216-837-11 METAL CHIP 22K 5% 1/10W
R7854 1-216-864-11 SHORT CHIP 0
R7858 1-216-809-11 METAL CHIP 100 5% 1/10W
R7859 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7860 1-216-837-11 METAL CHIP 22K 5% 1/10W
R7861 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7863 1-216-837-11 METAL CHIP 22K 5% 1/10W
R7864 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7865 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7866 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R7867 1-216-817-11 METAL CHIP 470 5% 1/10W
R7877 1-216-864-11 SHORT CHIP 0
R7878 1-216-864-11 SHORT CHIP 0
R7883 1-216-864-11 SHORT CHIP 0
R7885 1-216-864-11 SHORT CHIP 0
R7886 1-216-864-11 SHORT CHIP 0
R7888 1-216-803-11 METAL CHIP 33 5% 1/10W
R7890 1-216-295-91 SHORT CHIP 0
R7891 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R7892 1-218-891-11 METAL CHIP 68K 0.5% 1/10W
R7893 1-218-911-11 METAL CHIP 470K 0.5% 1/10W
R7894 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7896 1-216-295-91 SHORT CHIP 0
R7897 1-216-295-91 SHORT CHIP 0
R7909 1-216-864-11 SHORT CHIP 0
R7910 1-216-797-11 METAL CHIP 10 5% 1/10W
R7911 1-216-797-11 METAL CHIP 10 5% 1/10W
R7912 1-216-803-11 METAL CHIP 33 5% 1/10W
R7913 1-216-797-11 METAL CHIP 10 5% 1/10W
R7914 1-216-797-11 METAL CHIP 10 5% 1/10W
R7915 1-216-797-11 METAL CHIP 10 5% 1/10W
R7919 1-216-821-11 METAL CHIP 1K 5% 1/10W
R7940 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7941 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7952 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7954 1-216-845-11 METAL CHIP 100K 5% 1/10W
R7987 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7989 1-216-845-11 METAL CHIP 100K 5% 1/10W
R7991 1-216-864-11 SHORT CHIP 0
R7992 1-216-864-11 SHORT CHIP 0
R7994 1-216-864-11 SHORT CHIP 0
R7997 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7998 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8000 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R8002 1-216-864-11 SHORT CHIP 0
< NETWORK RESISTOR >
RB7900 1-234-371-21 RES, NETWORK 47 (1005X4)
RB7901 1-234-371-21 RES, NETWORK 47 (1005X4)
RB7902 1-242-963-21 RES, NETWORK 33 (1005X4)
RB7903 1-234-369-21 RES, NETWORK 10 (1005X4)
RB7904 1-234-369-21 RES, NETWORK 10 (1005X4)
RB7905 1-234-369-21 RES, NETWORK 10 (1005X4)
RB7906 1-234-369-21 RES, NETWORK 10 (1005X4)
RB7907 1-234-369-21 RES, NETWORK 10 (1005X4)
RB7908 1-234-369-21 RES, NETWORK 10 (1005X4)
RB7909 1-234-369-21 RES, NETWORK 10 (1005X4)
RB7910 1-234-369-21 RES, NETWORK 10 (1005X4)
RB7911 1-234-369-21 RES, NETWORK 10 (1005X4)
RB7913 1-234-400-21 CONDUCTOR, NETWORK (2010X4)
RB7914 1-242-963-21 RES, NETWORK 33 (1005X4)
RB7916 1-234-400-21 CONDUCTOR, NETWORK (2010X4)
RB7917 1-234-400-21 CONDUCTOR, NETWORK (2010X4)
< TUNER >
TU7800 8-597-505-00 TUNER UNIT, DIGITAL BTD-CA811Z
**************************************************************
* A-1073-391-A QU BOARD, COMPLETE
**********************
< CAPACITOR >
C7951 1-115-156-11 CERAMIC CHIP 1UF 10V
C7952 1-115-156-11 CERAMIC CHIP 1UF 10V
C7953 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C7954 1-164-156-11 CERAMIC CHIP 0.1UF 25V
< CONNECTOR >
CN7951 1-573-768-21 PIN, CONNECTOR (1.5MM) (SMD)5P
CN7952 1-818-486-11 PCMCIA CONNECTOR (SMD)
CN7953 1-818-483-11 FFC/FPC CONNECTOR (ZIF) 80P
< TEST POINT >
TP7950 1-694-766-21 TERMINAL (ONBOARD CONTACT)
**************************************************************
A-1103-767-A S2 BOARD, COMPLETE
*********************
< CAPACITOR >
C7180 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C7181 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C7182 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C7183 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
< CONNECTOR >
CN7180 1-819-333-11 HEADER ASSEMBLY FOR PWB 5P
< IC >
IC7180 6-707-223-01 IC LM75BIM-5/NOPB
< RESISTOR >
R7181 1-216-801-11 METAL CHIP 22 5% 1/10W
R7182 1-216-801-11 METAL CHIP 22 5% 1/10W
R7185 1-216-864-11 SHORT CHIP 0
R7186 1-216-864-11 SHORT CHIP 0
R7187 1-216-864-11 SHORT CHIP 0
***************************************************************
QT QU S2
