Sony MAP-S1 - Electrical Parts List Continued; Connectors, Diodes, Fuses, and ICs

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAP-S1
105105
C952 1-124-779-00 ELECT CHIP 10uF 20% 16V
C953 1-124-779-00 ELECT CHIP 10uF 20% 16V
C954 1-127-967-21 FILM CHIP 0.0022uF 5% 50V
C955 1-127-967-21 FILM CHIP 0.0022uF 5% 50V
C956 1-127-967-21 FILM CHIP 0.0022uF 5% 50V
C957 1-127-967-21 FILM CHIP 0.0022uF 5% 50V
C958 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C959 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C960 1-117-681-11 ELECT CHIP 100uF 20% 16V
C961 1-117-681-11 ELECT CHIP 100uF 20% 16V
C962 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C963 1-218-990-81 SHORT CHIP 0
C964 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C970 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C971 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C974 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C975 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN002 1-820-112-41 CONNECTOR, FFC/FPC 9P
CN003 1-784-387-51 CONNECTOR, FFC/FPC 31P
CN004 1-822-067-51 CONNECTOR, FFC/FPC 5P
* CN005 1-779-993-41 PIN, CONNECTOR (PWB) 5P
CN006 1-820-121-41 CONNECTOR, FFC/FPC 23P
CN007 1-794-509-11 PIN, CONNECTOR (PC BOARD) (3P)
CN008 1-815-460-31 CONNECTOR, FFC/FPC 26P
CN009 1-779-992-11 PIN, CONNECTOR (PWB) 8P
CN010 1-820-112-41 CONNECTOR, FFC/FPC 9P
CN012 1-820-112-41 CONNECTOR, FFC/FPC 9P
(AEP, UK, AUS, HK, MY)
CN202 1-779-071-41 CONNECTOR, FFC/FPC 16P
CN501 1-580-789-21 PIN, CONNECTOR (SMD) 6P
CN502 1-785-466-41 CONNECTOR, FFC/FPC 7P
CN503 1-843-557-11 FFC ST CONNECTOR (NON-ZIF) 24P
CN701 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN702 1-779-992-11 PIN, CONNECTOR (PWB) 8P
CN703 1-779-992-11 PIN, CONNECTOR (PWB) 8P
CN851 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
< DIODE >
D001 6-502-961-01 DIODE DA2J10100L
D002 6-503-705-01 DIODE SJPJ-L3SVL
D201 6-502-961-01 DIODE DA2J10100L
D203 6-502-961-01 DIODE DA2J10100L
D701 6-503-705-01 DIODE SJPJ-L3SVL
D702 6-503-705-01 DIODE SJPJ-L3SVL
D703 6-503-705-01 DIODE SJPJ-L3SVL
D704 6-503-705-01 DIODE SJPJ-L3SVL
D705 6-502-970-01 DIODE DZ2J068M0L
D707 6-503-857-01 DIODE BAW56
D709 6-503-857-01 DIODE BAW56
D710 6-502-966-01 DIODE DZ2J056M0L
D851 8-719-069-29 DIODE RB520S-30FJTE61
D852 8-719-069-29 DIODE RB520S-30FJTE61
< FERRITE BEAD >
FB001 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB002 1-481-746-11 SDM EMI FERRITE
FB003 1-481-746-11 SDM EMI FERRITE
FB004 1-481-746-11 SDM EMI FERRITE
FB005 1-481-746-11 SDM EMI FERRITE
FB006 1-481-746-11 SDM EMI FERRITE
FB007 1-481-746-11 SDM EMI FERRITE
FB008 1-481-746-11 SDM EMI FERRITE
FB009 1-469-324-21 FERRITE, EMI (SMD) (2012)
(AEP, UK, AUS, HK, MY)
FB200 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB502 1-481-348-21 EMI FERRITE (SMD) (1608)
FB514 1-481-348-21 EMI FERRITE (SMD) (1608)
FB516 1-400-580-21 FERRITE, EMI (SMD)
FB517 1-481-348-21 EMI FERRITE (SMD) (1608)
FB518 1-481-348-21 EMI FERRITE (SMD) (1608)
< FILTER >
FL501 1-234-494-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC001 6-721-030-01 IC MM3526A33NRE
IC200 (Not supplied) IC MFI337S3959 (See Note)
IC201 (Not supplied) IC TCA6424ARGJR (See Note)
IC202 (Not supplied) IC MX25L6435EM2I-10G (See Note)
IC203 6-721-341-01 IC R7S7200032CFP
IC204 6-719-856-01 IC BU4229F-TR
IC501 6-712-033-01 IC MM1701CHBE
IC502 (Not supplied) IC W25Q16CVSSIG-R (See Note)
IC503 6-718-440-01 IC CXD90013R
IC504 6-718-430-01 IC EM638165 TSB-6G
IC505 6-716-832-01 IC MM3374A33PRE
* IC701 6-718-479-11 IC TPS54332CDDAR
* IC702 6-718-479-11 IC TPS54332CDDAR
* IC703 6-718-479-11 IC TPS54332CDDAR
* IC704 6-718-479-11 IC TPS54332CDDAR
IC707 6-708-254-01 IC BA00CC0WFP
IC709 6-716-832-01 IC MM3374A33PRE
IC710 6-719-012-01 IC S-13A1A12-E6T1U3
IC851 6-716-462-01 IC BD00GA3WEFJ-E2
IC852 6-720-195-01 IC AM5890S
IC901 8-759-524-09 IC TC74VHC153FT (EL)
IC902 8-759-524-09 IC TC74VHC153FT (EL)
IC903 8-759-524-29 IC TC74VHC257FT (EL)
IC904 8-759-524-09 IC TC74VHC153FT (EL)
IC905 8-759-598-43 IC TC7WH04FK
IC906 8-759-598-43 IC TC7WH04FK
IC907 6-715-699-01 IC CS230002-CZZR
IC908 8-759-096-87 IC TC7WU04FU (TE12R)
IC909 8-759-096-87 IC TC7WU04FU (TE12R)
IC910 8-759-524-29 IC TC74VHC257FT (EL)
IC911 6-710-554-01 IC PCM1808PWR
IC913 6-720-672-01 IC PCM1795DBR
IC914 6-705-973-01 IC PCM1754DBQR
IC915 6-712-384-01 IC TC74VHC4052AFT (EK)
IC916 8-759-422-21 IC NJM4580V (TE2)
IC917 8-759-422-21 IC NJM4580V (TE2)
IC918 8-759-422-21 IC NJM4580V (TE2)
IC919 8-759-680-48 IC TC7WH157FK
< JUMPER RESISTOR >
JC003 1-216-864-11 SHORT CHIP 0
JC004 1-216-864-11 SHORT CHIP 0
JC005 1-216-864-11 SHORT CHIP 0
JC006 1-216-864-11 SHORT CHIP 0
JC200 1-216-864-11 SHORT CHIP 0
Note: IC200, IC201, IC202 and IC502 on the MAIN board cannot re-
place with single. When these parts are damaged, replace the com-
plete mounted board.
MAIN
