MAP-S1

2-23. AC INLET (2P) (AC1)

1 Cut the binding band (taiton).

3 clamp filter

(ferrite core)

(FC4)

5 AC inlet (2P)

(AC1)

4 claw

AC inlet

(2P) (AC1)

AC inlet

(2P) (AC1)

20 ± 5 mm

+RZWRLQVWDOOWKHFODPSILOWHUIHUULWHFRUH)&

clamp filter

(ferrite core)

(FC4)

2 filament tape

(sub material)

[gray]

[white]

binding band

(taiton)

bracket

PWB NET

$&LQOHW3$&VHWWLQJ

Note:

During reassembly, use new

binding band (taiton) to fasten

the wires back in place as

they were before disassembly.
