MAP-S1
12
SECTION 2
DISASSEMBLY
This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SET
2-2. PANEL (SIDE L/R)
(Page 13)
2-3. PANEL (FRONT) BLOCK-1
(Page 13)
2-4. PANEL (FRONT) BLOCK-2
(Page 14)
2-6. FRONT-R BOARD,
FRONT-KEY BOARD
(Page 15)
2-7. FRONT-EJECT BOARD,
FRONT-L BOARD
(Page 16)
2-14. OPTICAL PICK-UP BLOCK
(CMS-S76RFS7G) (OP1)
(Page 21)
2-12. FFC GUIDE
(Page 19)
2-13. BOTTOM COVER (I)
(Page 20)
2-26. MAIN BOARD
(Page 31)
2-27. POWER BOARD
(Page 32)
2-28. MAIN TRANS (T1)
(Page 32)
2-24. AMP BOARD BLOCK
(Page 29)
2-25. AMP BOARD
(Page 30)
2-9. HOLDER BT NFC BLOCK
(Page 17)
2-20. ANTENNA 2.4 GHz (ANT1),
HOLDER (ANTENNA)
(Page 26)
2-11. CD MECHANISM DECK
(CDM91A-DVBU203)
(Page 19)
2-5. BRACKET JACK BLOCK
(Page 15)
2-10. CD MECHANISM DECK BLOCK
(Page 18)
2-15. TUNER BOARD BLOCK
(Page 22)
2-19. PANEL BACK BLOCK
(Page 25)
2-23. AC INLET (2P) (AC1)
(Page 28)
2-16. TUNER BOARD
(Page 23)
2-17. DAB BOARD BLOCK
(Except Canadian model)
(Page 24)
2-21. NETWORK BOARD
BLOCK
(Page 26)
2-22. WiFi MODULE (WIFI1),
NETWORK BOARD
(Page 27)
2-18. MODULE
(DAB TUNER)
(DAB1),
DAB BOARD
(Except Canadian
model)
(Page 24)
2-8. FRONT BOARD
(Page 16)
