98
MAP-S1
SECTION 7
ELECTRICAL PARTS LIST
A-2057-116-A AMP BOARD, COMPLETE
********************
3-905-609-13 SCREW (TRANSISTOR)
< CAPACITOR/RESISTOR >
C2001 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2002 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2003 1-116-870-11 ELECT 220uF 20% 16V
C2004 1-116-870-11 ELECT 220uF 20% 16V
C2005 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2006 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2007 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2008 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2009 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2010 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
* C2011 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2014 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2015 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2016 1-116-870-11 ELECT 220uF 20% 16V
C2017 1-116-870-11 ELECT 220uF 20% 16V
C2020 1-116-870-11 ELECT 220uF 20% 16V
C2021 1-116-870-11 ELECT 220uF 20% 16V
C2022 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2023 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2024 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C2025 1-126-964-11 ELECT 10uF 20% 50V
C2027 1-216-821-11 METAL CHIP 1K 5% 1/10W
(Suffi x-11) (See Note)
C2028 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C2029 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C2030 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C2034 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2035 1-126-968-11 ELECT 100uF 20% 50V
C2036 1-126-964-11 ELECT 10uF 20% 50V
C2037 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2038 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2039 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2040 1-126-964-11 ELECT 10uF 20% 50V
C2043 1-116-988-11 ELECT 4700uF 20% 35V
C2044 1-116-988-11 ELECT 4700uF 20% 35V
C2045 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C2046 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C2047 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C2048 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C2049 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(Suffi x-12) (See Note)
C2702 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2703 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2704 1-112-100-11 ELECT 10uF 20% 50V
C2705 1-112-100-11 ELECT 10uF 20% 50V
C2706 1-112-100-11 ELECT 10uF 20% 50V
C2707 1-112-083-11 ELECT 100uF 20% 16V
C2708 1-112-099-11 ELECT 4.7uF 20% 50V
C2709 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2710 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C2711 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C2712 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C2713 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C2715 1-116-857-91 CERAMIC CHIP 0.22uF 10% 50V
C2716 1-116-857-91 CERAMIC CHIP 0.22uF 10% 50V
C2717 1-112-100-11 ELECT 10uF 20% 50V
C2718 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C2725 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2726 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
C2727 1-137-190-91 FILM 0.22uF 5% 50V
C2728 1-137-190-91 FILM 0.22uF 5% 50V
C2729 1-116-299-91 CERAMIC CHIP 220PF 1% 50V
C2732 1-112-083-11 ELECT 100uF 20% 16V
* C2735 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2736 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2737 1-137-958-91 MYLAR 0.22uF 5% 100V
C2739 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C2749 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C2902 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2903 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2904 1-112-100-11 ELECT 10uF 20% 50V
C2905 1-112-100-11 ELECT 10uF 20% 50V
C2906 1-112-100-11 ELECT 10uF 20% 50V
C2907 1-112-083-11 ELECT 100uF 20% 16V
C2908 1-112-099-11 ELECT 4.7uF 20% 50V
C2909 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2910 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C2911 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C2912 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C2913 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C2915 1-116-857-91 CERAMIC CHIP 0.22uF 10% 50V
C2916 1-116-857-91 CERAMIC CHIP 0.22uF 10% 50V
C2917 1-112-100-11 ELECT 10uF 20% 50V
C2918 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AUS : Australian model
CND : Canadian model
HK : Hong Kong model
MY : Malaysia model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
Note: Refer to the “NEW/FORMER DISCRIMINATION OF MAIN, NETWORK,
FRONT-L AND AMP BOARDS” on page 4 for how to distinguish suffi x-11
and suffi x-12 of AMP board for Canadian model.
AMP
To Next Page
