Sony MAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAP-S1
9999
C2925 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2926 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
C2927 1-137-190-91 FILM 0.22uF 5% 50V
C2928 1-137-190-91 FILM 0.22uF 5% 50V
C2929 1-116-299-91 CERAMIC CHIP 220PF 1% 50V
C2932 1-112-083-11 ELECT 100uF 20% 16V
* C2935 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2936 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2937 1-137-958-91 MYLAR 0.22uF 5% 100V
C2939 1-100-831-91 CERAMIC CHIP 0.001uF 2% 50V
C2949 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C2951 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C2952 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN2001 1-820-112-41 CONNECTOR, FFC/FPC 9P
* CN2003 1-564-104-00 PIN, CONNECTOR (3.96 mm PITCH) 3P
< DIODE >
D2001 6-503-026-01 DIODE DZ2J120M0L
D2002 6-502-994-01 DIODE D10XB60 F
D2701 8-719-081-97 DIODE MMDL914T1
D2702 8-719-081-97 DIODE MMDL914T1
D2901 8-719-081-97 DIODE MMDL914T1
D2902 8-719-081-97 DIODE MMDL914T1
< FUSE >
0 F2001 1-532-504-33 FUSE (T 4 AL/250 V)
0 F2002 1-532-504-33 FUSE (T 4 AL/250 V)
< FERRITE BEAD >
FB2019 1-481-348-21 EMI FERRITE (SMD) (1608) (Suffi x-12)
(See Note 1)
< FUSE HOLDER >
FH2001 1-533-217-31 FUSE HOLDER
FH2002 1-533-217-31 FUSE HOLDER
FH2003 1-533-217-31 FUSE HOLDER
FH2004 1-533-217-31 FUSE HOLDER
< IC >
IC2001 6-720-687-01 IC NJW1194
IC2003 (Not supplied) IC IRS2052M (See Note 2)
IC2004 6-712-109-01 IC KIA7815API-U/PF
IC2005 6-712-107-01 IC KIA7915PI
IC2006 6-712-295-01 IC KIA7907PI
IC2007 6-712-294-01 IC KIA7807API-U/PF
IC2008 6-713-031-01 IC KIA7805API-U/PF
IC2009 6-711-998-01 IC KIA7905PI
IC2010 8-759-422-21 IC NJM4580V (TE2)
IC2011 8-759-422-21 IC NJM4580V (TE2)
IC2012 8-759-422-21 IC NJM4580V (TE2)
< JACK >
J2001 1-794-982-11 JACK, PIN 4P (LINE IN, LINE OUT)
< JUMPER RESISTOR/FERRITE BEAD >
JC2000 1-216-864-11 SHORT CHIP 0
JC2011 1-216-864-11 SHORT CHIP 0
JC2012 1-216-864-11 SHORT CHIP 0
JC2013 1-216-864-11 SHORT CHIP 0
JC2016 1-216-864-11 SHORT CHIP 0
JC2017 1-216-864-11 SHORT CHIP 0
JC2019 1-481-348-21 EMI FERRITE (SMD) (1608) (Suffi x-11)
(See Note 1)
JC2020 1-216-864-11 SHORT CHIP 0
JC2021 1-216-864-11 SHORT CHIP 0
JC2022 1-216-864-11 SHORT CHIP 0
JC2023 1-216-864-11 SHORT CHIP 0
JC2024 1-216-864-11 SHORT CHIP 0
JC2025 1-216-864-11 SHORT CHIP 0
JC2026 1-216-864-11 SHORT CHIP 0
JC2027 1-216-864-11 SHORT CHIP 0
JC2028 1-216-864-11 SHORT CHIP 0
JC2029 1-216-864-11 SHORT CHIP 0
JC2032 1-216-864-11 SHORT CHIP 0
JC2033 1-216-864-11 SHORT CHIP 0
JC2034 1-216-864-11 SHORT CHIP 0
< COIL >
L2701 1-482-223-11 7G23C POWER INDUCTOR 15uH
L2901 1-482-223-11 7G23C POWER INDUCTOR 15uH
< TRANSISTOR >
Q2001 8-729-013-26 TRANSISTOR HN1C03FU-TE85R
Q2002 8-729-056-46 TRANSISTOR 2SC5053T100Q
Q2003 6-553-268-01 TRANSISTOR PDTC114ET
Q2004 6-553-246-01 TRANSISTOR PDTA114ET
Q2005 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q2006 8-729-013-26 TRANSISTOR HN1C03FU-TE85R
Q2010 6-552-891-01 TRANSISTOR LSAR523UBFS8TL
Q2011 6-553-268-01 TRANSISTOR PDTC114ET
Q2012 6-552-891-01 TRANSISTOR LSAR523UBFS8TL
Q2701 (Not supplied) FET IRF6665TR1PBF (See Note 2)
Q2702 (Not supplied) FET IRF6665TR1PBF (See Note 2)
Q2703 8-729-427-72 TRANSISTOR XP4501
Q2901 (Not supplied) FET IRF6665TR1PBF (See Note 2)
Q2902 (Not supplied) FET IRF6665TR1PBF (See Note 2)
Q2903 8-729-427-72 TRANSISTOR XP4501
< RESISTOR >
R2001 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2003 1-216-797-11 METAL CHIP 10 5% 1/10W
R2004 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R2005 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2006 1-216-853-11 METAL CHIP 470K 5% 1/10W
R2007 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2008 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2009 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2010 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2012 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2014 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2016 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R2017 1-216-793-11 METAL CHIP 4.7 5% 1/10W
0 R2019 1-257-371-11 CARBON 1K 5% 1/2W F
R2020 1-216-837-11 METAL CHIP 22K 5% 1/10W
0 R2023 1-257-371-11 CARBON 1K 5% 1/2W F
0 R2024 1-257-371-11 CARBON 1K 5% 1/2W F
R2025 1-216-837-11 METAL CHIP 22K 5% 1/10W
Note 1: Refer to the “NEW/FORMER DISCRIMINATION OF MAIN, NET-
WORK, FRONT-L AND AMP BOARDS” on page 4 for how to dis-
tinguish suffi x-11 and suffi x-12 of AMP board for Canadian model.
Note 2: IC2003, Q2701, Q2702, Q2901 and Q2902 on the AMP
board cannot replace with single. When these parts are
damaged, replace the complete mounted board.
AMP

Sony MAP-S1 Specifications

General

Receiver type	stereo
Audio output channels	2.0 channels
Power output per channel (20-20KHz@8 Ohm)	100 W
HDMI in	0
Audio (L/R) in	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Ethernet LAN	Yes
Supported radio bands	AM, FM
Optical drive type	CD player
Card reader integrated	No
Display	-
Product color	Silver
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.4 W
Power consumption (typical)	55 W
