Sony MAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAP-S1
100
R2027 1-216-821-11 METAL CHIP 1K 5% 1/10W
(Suffi x-12) (See Note)
R2703 1-216-206-00 RES-CHIP 2.2K 2% 1/8W
R2704 1-216-238-00 RES-CHIP 47K 2% 1/8W
R2705 1-216-206-00 RES-CHIP 2.2K 2% 1/8W
R2706 1-216-238-00 RES-CHIP 47K 2% 1/8W
R2707 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R2708 1-216-246-00 RES-CHIP 100K 2% 1/8W
R2711 1-216-206-00 RES-CHIP 2.2K 2% 1/8W
R2712 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R2713 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
0 R2714 1-215-857-31 METAL OXIDE 10 5% 1W F
0 R2715 1-257-372-11 CARBON 2.2K 5% 1/2W F
R2716 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R2717 1-257-444-11 CARBON 22K 5% 1/2W F
0 R2718 1-257-371-11 CARBON 1K 5% 1/2W F
R2721 1-216-246-00 RES-CHIP 100K 2% 1/8W
R2722 1-208-782-11 METAL CHIP 1K 0.5% 1/10W
R2724 1-216-296-11 SHORT CHIP 0
R2725 1-216-174-00 RES-CHIP 100 2% 1/8W
R2726 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2729 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R2730 1-208-405-41 RES-CHIP 47 2% 1/8W
R2731 1-208-405-41 RES-CHIP 47 2% 1/8W
R2732 1-257-362-21 METAL CHIP 1 5% 1/2W
R2733 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2734 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2735 1-216-845-11 METAL CHIP 100K 5% 1/10W
0 R2736 1-257-414-11 CARBON 100 5% 1/2W F
R2737 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2738 1-216-238-00 RES-CHIP 47K 2% 1/8W
R2739 1-208-782-11 METAL CHIP 1K 0.5% 1/10W
R2740 1-216-222-00 RES-CHIP 10K 2% 1/8W
R2741 1-216-222-00 RES-CHIP 10K 2% 1/8W
R2742 1-216-206-00 RES-CHIP 2.2K 2% 1/8W
R2743 1-216-206-00 RES-CHIP 2.2K 2% 1/8W
R2903 1-216-206-00 RES-CHIP 2.2K 2% 1/8W
R2904 1-216-238-00 RES-CHIP 47K 2% 1/8W
R2905 1-216-206-00 RES-CHIP 2.2K 2% 1/8W
R2906 1-216-238-00 RES-CHIP 47K 2% 1/8W
R2907 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R2908 1-216-246-00 RES-CHIP 100K 2% 1/8W
R2911 1-216-206-00 RES-CHIP 2.2K 2% 1/8W
R2912 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R2913 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
0 R2914 1-215-857-31 METAL OXIDE 10 5% 1W F
0 R2915 1-257-372-11 CARBON 2.2K 5% 1/2W F
R2916 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R2917 1-257-444-11 CARBON 22K 5% 1/2W F
0 R2918 1-257-371-11 CARBON 1K 5% 1/2W F
R2921 1-216-246-00 RES-CHIP 100K 2% 1/8W
R2922 1-208-782-11 METAL CHIP 1K 0.5% 1/10W
R2924 1-216-296-11 SHORT CHIP 0
R2925 1-216-174-00 RES-CHIP 100 2% 1/8W
R2926 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2929 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R2930 1-208-405-41 RES-CHIP 47 2% 1/8W
R2931 1-208-405-41 RES-CHIP 47 2% 1/8W
R2932 1-257-362-21 METAL CHIP 1 5% 1/2W
R2933 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2934 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2935 1-216-845-11 METAL CHIP 100K 5% 1/10W
0 R2936 1-257-414-11 CARBON 100 5% 1/2W F
R2937 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2938 1-216-238-00 RES-CHIP 47K 2% 1/8W
R2939 1-208-782-11 METAL CHIP 1K 0.5% 1/10W
R2940 1-216-222-00 RES-CHIP 10K 2% 1/8W
R2941 1-216-222-00 RES-CHIP 10K 2% 1/8W
R2942 1-216-206-00 RES-CHIP 2.2K 2% 1/8W
R2943 1-216-206-00 RES-CHIP 2.2K 2% 1/8W
< TERMINAL >
TB2001 1-854-095-11 TERMINAL BOARD, SPEAKER (SPEAKERS)
< THERMISTOR >
TH001 1-805-553-21 THERMISTOR, POSITIVE
*************************************************************
A-1990-334-A DAB BOARD, COMPLETE
(AEP, UK, AUS, HK, MY)
********************
When the DAB board is defective, replace the complete mounted board.
*************************************************************
FRONT BOARD
************
4-154-640-01 SHEET (FL HOLDER), ADHESIVE
< CAPACITOR >
C4401 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C4402 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
* C4403 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C4404 1-116-705-11 CERAMIC CHIP 47uF 20% 16V
C4405 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C4407 1-118-093-91 CERAMIC CHIP 0.015uF 5% 100V
C4408 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C4409 1-116-707-11 CERAMIC CHIP 47uF 20% 10V
C4411 1-128-551-11 ELECT 22uF 20% 63V
C4412 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C4414 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C4415 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C4416 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C4417 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C4419 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4420 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C4421 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4422 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4424 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C4425 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C4427 1-116-707-11 CERAMIC CHIP 47uF 20% 10V
C4428 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
< CONNECTOR >
CN4401 1-779-556-21 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
< DIODE >
D4401 8-719-056-11 LED SML72423C-TP15
(POWER ON/STANDBY INDICATOR)
D4402 6-502-945-01 DIODE CRH01 (TE85R, Q)
Note: Refer to the “NEW/FORMER DISCRIMINATION OF MAIN, NETWORK,
FRONT-L AND AMP BOARDS” on page 4 for how to distinguish suffi x-12 of
AMP board for Canadian model.
AMP DAB FRONT

Sony MAP-S1 Specifications

General

Receiver type	stereo
Audio output channels	2.0 channels
Power output per channel (20-20KHz@8 Ohm)	100 W
HDMI in	0
Audio (L/R) in	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Ethernet LAN	Yes
Supported radio bands	AM, FM
Optical drive type	CD player
Card reader integrated	No
Display	-
Product color	Silver
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.4 W
Power consumption (typical)	55 W
