Sony MAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAP-S1
101101
D4403 6-502-945-01 DIODE CRH01 (TE85R, Q)
D4404 6-503-856-01 DIODE PMEG3010EJ
D4405 6-502-945-01 DIODE CRH01 (TE85R, Q)
D4406 6-503-856-01 DIODE PMEG3010EJ
D4407 6-503-856-01 DIODE PMEG3010EJ
D4408 6-503-856-01 DIODE PMEG3010EJ
D4409 6-500-354-01 DIODE PTZ-TE25-3.6B
D4410 6-502-945-01 DIODE CRH01 (TE85R, Q)
< JUMPER RESISTOR >
JC4401 1-216-864-11 SHORT CHIP 0
JC4402 1-216-864-11 SHORT CHIP 0
JC4403 1-216-864-11 SHORT CHIP 0
JC4404 1-216-864-11 SHORT CHIP 0
JC4405 1-216-864-11 SHORT CHIP 0
JC4406 1-216-864-11 SHORT CHIP 0
JC4407 1-216-864-11 SHORT CHIP 0
JC4408 1-216-864-11 SHORT CHIP 0
JC4409 1-216-864-11 SHORT CHIP 0
JC4410 1-216-864-11 SHORT CHIP 0
JC4411 1-216-864-11 SHORT CHIP 0
JC4412 1-216-864-11 SHORT CHIP 0
JC4413 1-216-864-11 SHORT CHIP 0
JC4414 1-216-864-11 SHORT CHIP 0
JR4401 1-216-296-11 SHORT CHIP 0
JR4402 1-216-296-11 SHORT CHIP 0
JR4403 1-216-296-11 SHORT CHIP 0
< COIL >
L4401 1-460-698-11 POWER INDUCTOR
< FLUORESCENT INDICATOR TUBE >
ND4401 1-483-521-11 VACUUM_FLUORESCENT_DISPLAY
< TRANSISTOR >
Q4403 6-553-492-01 TRANSISTOR 2SC5866TLR
Q4404 6-553-492-01 TRANSISTOR 2SC5866TLR
Q4405 6-552-922-01 TRANSISTOR LTA014EUBFS8TL
Q4406 6-552-922-01 TRANSISTOR LTA014EUBFS8TL
< RESISTOR >
R4401 1-250-596-11 METAL CHIP 150 1% 1/10W
R4402 1-250-596-11 METAL CHIP 150 1% 1/10W
R4403 1-216-818-11 METAL CHIP 560 5% 1/10W
R4404 1-216-818-11 METAL CHIP 560 5% 1/10W
R4405 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4406 1-216-170-00 METAL CHIP 68 5% 1/8W
R4407 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4408 1-216-797-11 METAL CHIP 10 5% 1/10W
R4409 1-216-797-11 METAL CHIP 10 5% 1/10W
R4410 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R4411 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R4412 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R4413 1-216-797-11 METAL CHIP 10 5% 1/10W
R4414 1-216-797-11 METAL CHIP 10 5% 1/10W
R4416 1-216-846-11 METAL CHIP 120K 5% 1/10W
< SWITCH >
S4401 1-762-875-21 SWITCH, KEYBOARD (
@
/
1
)
< TRANSFORMER >
T4401 1-697-345-11 DC/DC CONV. TRANS.
*************************************************************
FRONT-EJECT BOARD
******************
< CAPACITOR >
C3500 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
< JUMPER RESISTOR >
JC3500 1-216-864-11 SHORT CHIP 0
JC3501 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R3500 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S3500 1-798-448-11 TACTILE SWITCH (Z)
*************************************************************
FRONT-KEY BOARD
****************
< CAPACITOR >
C3510 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C3512 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
< ROTARY ENCODER >
EN3510 1-487-023-22 ROTARY ENCODER
(− TUNING +, .
>, PUSH ENTER)
< JUMPER RESISTOR >
JC3512 1-216-864-11 SHORT CHIP 0
JC3513 1-216-864-11 SHORT CHIP 0
JC3514 1-216-864-11 SHORT CHIP 0
JC3516 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R3510 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R3512 1-216-864-11 SHORT CHIP 0
R3513 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3514 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R3515 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3516 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S3510 1-762-875-21 SWITCH, KEYBOARD (u)
S3511 1-762-875-21 SWITCH, KEYBOARD (MENU)
S3512 1-762-875-21 SWITCH, KEYBOARD (BACK)
*************************************************************
FRONT-L BOARD
*************
< CAPACITOR >
C4801 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4802 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C4803 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C4806 1-116-705-11 CERAMIC CHIP 47uF 20% 16V
FRONT FRONT-EJECT FRONT-KEY FRONT-L

Sony MAP-S1 Specifications

General

Receiver type	stereo
Audio output channels	2.0 channels
Power output per channel (20-20KHz@8 Ohm)	100 W
HDMI in	0
Audio (L/R) in	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Ethernet LAN	Yes
Supported radio bands	AM, FM
Optical drive type	CD player
Card reader integrated	No
Display	-
Product color	Silver
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.4 W
Power consumption (typical)	55 W
