Sony MAP-S1 Service Manual

90
MAP-S1
6-3. FRONT-L BOARD SECTION
• Rear bottom view
101 3-087-053-01 +BVTP2.6 (3CR)
102 3-254-029-01 SCREW
103 3-077-331-21 +BV3 (3-CR)
104 A-1990-321-A USB BOARD, COMPLETE
105 4-485-542-01 BUTTON (EJECT) (
Z
)
106 X-2588-668-1 KNOB (VOLUME/S) ASSY
107 X-2588-669-1 KNOB (ENTER/S) ASSY
108 4-485-545-01 WINDOW (IR)
EN3521 1-480-109-11 ENCODER, ROTARY (Including NUT) (VOL)
FFC3 9-885-194-24 FY14 FFC (1.0 mm_5P_USB)
FFC4 9-885-194-22 FY14 FFC (1.0 mm_9P_VOL)
#2 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
101
101
101
101
101
101
101
102
102
101
101
not supplied
(FRONT-KEY board)
not supplied
(FRONT-R board)
supplied with
EN3521
EN3521
not supplied
(FRONT-L board)
not supplied
(HP board)
not supplied
not supplied
not supplied
(FRONT-EJECT board)
FFC3
FFC4
not supplied
not supplied
#2
#2
#2
#2
#2
#2
B
C
C
D
D
E
E
F
F
B
101
101
101
103
103
104
105
106
107
108
panel (front) section
(AEP, UK,
AUS, HK,
MY)

Sony MAP-S1 Specifications

General

Receiver type	stereo
Audio output channels	2.0 channels
Power output per channel (20-20KHz@8 Ohm)	100 W
HDMI in	0
Audio (L/R) in	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Ethernet LAN	Yes
Supported radio bands	AM, FM
Optical drive type	CD player
Card reader integrated	No
Display	-
Product color	Silver
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.4 W
Power consumption (typical)	55 W
