MAP-S1
20
2-13. BOTTOM COVER (I)
5
bottom cover (I)
4 two screws
(PTP2 u 5)
4 two screws
(PTP2 u 5)
2
two claws
1
claw
3 cover sheet
– CD mechanism deck block bottom view –
