Sony MAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAP-S1
102
C4808 1-116-705-11 CERAMIC CHIP 47uF 20% 16V
C4810 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C4812 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C4813 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C4814 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN4801 1-815-762-31 CONNECTOR, FFC/FPC (LIF) 14P
CN4802 1-820-384-31 CONNECTOR, FFC/FPC (LIF) 8P
CN4803 1-815-460-31 CONNECTOR, FFC/FPC 26P
CN4804 1-794-362-51 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 5P
CN4805 1-820-117-41 CONNECTOR, FFC/FPC 19P
CN4806 1-820-121-41 CONNECTOR, FFC/FPC 23P
CN4807 1-820-112-41 CONNECTOR, FFC/FPC 9P
< IC >
IC4803 6-717-191-01 IC KIA7812AF-RTF/PW
< RESISTOR >
R4801 1-218-941-81 METAL CHIP 100 5% 1/16W
R4804 1-216-809-11 METAL CHIP 100 5% 1/10W
R4805 1-216-809-11 METAL CHIP 100 5% 1/10W
R4806 1-216-809-11 METAL CHIP 100 5% 1/10W
R4807 1-216-809-11 METAL CHIP 100 5% 1/10W
R4808 1-216-809-11 METAL CHIP 100 5% 1/10W
R4809 1-216-809-11 METAL CHIP 100 5% 1/10W
R4810 1-216-809-11 METAL CHIP 100 5% 1/10W
R4811 1-216-809-11 METAL CHIP 100 5% 1/10W
R4812 1-216-809-11 METAL CHIP 100 5% 1/10W
R4813 1-216-809-11 METAL CHIP 100 5% 1/10W
R4814 1-216-809-11 METAL CHIP 100 5% 1/10W
R4815 1-216-809-11 METAL CHIP 100 5% 1/10W
R4816 1-216-809-11 METAL CHIP 100 5% 1/10W
R4817 1-216-809-11 METAL CHIP 100 5% 1/10W
R4818 1-216-809-11 METAL CHIP 100 5% 1/10W
R4819 1-216-809-11 METAL CHIP 100 5% 1/10W
R4820 1-216-809-11 METAL CHIP 100 5% 1/10W
R4821 1-216-809-11 METAL CHIP 100 5% 1/10W
R4822 1-216-849-11 METAL CHIP 220K 5% 1/10W
R4823 1-216-849-11 METAL CHIP 220K 5% 1/10W
R4824 1-216-849-11 METAL CHIP 220K 5% 1/10W
R4826 1-216-841-11 METAL CHIP 47K 5% 1/10W
*************************************************************
FRONT-R BOARD
**************
< CAPACITOR >
C3521 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN3520 1-779-546-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< ENCODER, ROTARY >
EN3521 1-480-109-11 ENCODER, ROTARY (Including NUT) (VOL)
< IC >
IC3520 6-600-768-01 IC PNA4823M03S0 (
)
< JUMPER RESISTOR >
JC3522 1-216-864-11 SHORT CHIP 0
JC3523 1-216-864-11 SHORT CHIP 0
JC3524 1-216-864-11 SHORT CHIP 0
JC3525 1-216-864-11 SHORT CHIP 0
JC3526 1-216-864-11 SHORT CHIP 0
JC3527 1-216-864-11 SHORT CHIP 0
JC3528 1-216-864-11 SHORT CHIP 0
JC3529 1-216-864-11 SHORT CHIP 0
JC3530 1-216-864-11 SHORT CHIP 0
JC3531 1-216-864-11 SHORT CHIP 0
JC3532 1-216-864-11 SHORT CHIP 0
JC3533 1-216-864-11 SHORT CHIP 0
JC3534 1-216-864-11 SHORT CHIP 0
JC3535 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R3520 1-216-805-11 METAL CHIP 47 5% 1/10W
R3522 1-216-809-11 METAL CHIP 100 5% 1/10W
R3523 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3524 1-216-864-11 SHORT CHIP 0
*************************************************************
HP BOARD
*********
< CAPACITOR >
C4201 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C4202 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C4203 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN4201 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< JACK >
J4201 1-822-967-12 JACK (PHONES)
< JUMPER RESISTOR >
JC4201 1-216-864-11 SHORT CHIP 0
JC4202 1-216-864-11 SHORT CHIP 0
JC4203 1-216-864-11 SHORT CHIP 0
*************************************************************
A-2042-293-A MAIN BOARD, COMPLETE (for SERVICE) (CND)
A-2042-296-A MAIN BOARD, COMPLETE (for SERVICE)
(AEP, UK, HK, MY)
A-2042-297-A MAIN BOARD, COMPLETE (for SERVICE) (AUS)
********************
< CAPACITOR/JUMPER RESISTOR >
C001 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C002 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
(AEP, UK, AUS, HK, MY)
C003 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C004 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
(AEP, UK, AUS, HK, MY)
C005 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C006 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C007 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C008 1-218-990-81 SHORT CHIP 0
C009 1-218-990-81 SHORT CHIP 0
C010 1-218-990-81 SHORT CHIP 0
FRONT-L FRONT-R HP MAIN

Sony MAP-S1 Specifications

General

Receiver type	stereo
Audio output channels	2.0 channels
Power output per channel (20-20KHz@8 Ohm)	100 W
HDMI in	0
Audio (L/R) in	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Ethernet LAN	Yes
Supported radio bands	AM, FM
Optical drive type	CD player
Card reader integrated	No
Display	-
Product color	Silver
Volume control	Rotary
Apple docking compatibility	Not supported
Power consumption (standby)	0.4 W
Power consumption (typical)	55 W
