Sony MAP-S1 - Electrical Parts List Continued; Resistors

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAP-S1
108
R344 1-218-965-11 METAL CHIP 10K 5% 1/16W
R345 1-218-973-11 METAL CHIP 47K 5% 1/16W
R346 1-218-953-11 METAL CHIP 1K 5% 1/16W
R347 1-218-973-11 METAL CHIP 47K 5% 1/16W
R348 1-218-941-81 METAL CHIP 100 5% 1/16W
R349 1-218-941-81 METAL CHIP 100 5% 1/16W
R353 1-218-941-81 METAL CHIP 100 5% 1/16W
R354 1-218-941-81 METAL CHIP 100 5% 1/16W
R355 1-218-941-81 METAL CHIP 100 5% 1/16W
R356 1-218-990-81 SHORT CHIP 0
R357 1-218-941-81 METAL CHIP 100 5% 1/16W
R358 1-218-941-81 METAL CHIP 100 5% 1/16W
R359 1-218-941-81 METAL CHIP 100 5% 1/16W
R360 1-218-941-81 METAL CHIP 100 5% 1/16W
R361 1-218-953-11 METAL CHIP 1K 5% 1/16W
R362 1-218-941-81 METAL CHIP 100 5% 1/16W
R363 1-218-941-81 METAL CHIP 100 5% 1/16W
R364 1-218-941-81 METAL CHIP 100 5% 1/16W
R365 1-218-941-81 METAL CHIP 100 5% 1/16W
R370 1-218-965-11 METAL CHIP 10K 5% 1/16W
R372 1-218-965-11 METAL CHIP 10K 5% 1/16W
R373 1-218-941-81 METAL CHIP 100 5% 1/16W
R375 1-218-965-11 METAL CHIP 10K 5% 1/16W
R376 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R377 1-218-965-11 METAL CHIP 10K 5% 1/16W
R378 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R381 1-218-973-11 METAL CHIP 47K 5% 1/16W
R382 1-218-967-11 METAL CHIP 15K 5% 1/16W
R383 1-218-941-81 METAL CHIP 100 5% 1/16W
R384 1-218-990-81 SHORT CHIP 0
R385 1-218-990-81 SHORT CHIP 0
R386 1-218-990-81 SHORT CHIP 0
R387 1-218-941-81 METAL CHIP 100 5% 1/16W
R388 1-218-990-81 SHORT CHIP 0
R392 1-218-941-81 METAL CHIP 100 5% 1/16W
R393 1-218-941-81 METAL CHIP 100 5% 1/16W
R394 1-218-941-81 METAL CHIP 100 5% 1/16W
R398 1-218-977-11 METAL CHIP 100K 5% 1/16W
R399 1-218-977-11 METAL CHIP 100K 5% 1/16W
R402 1-218-941-81 METAL CHIP 100 5% 1/16W
R403 1-218-941-81 METAL CHIP 100 5% 1/16W
R404 1-218-941-81 METAL CHIP 100 5% 1/16W
R409 1-218-941-81 METAL CHIP 100 5% 1/16W
R410 1-218-941-81 METAL CHIP 100 5% 1/16W
R411 1-218-941-81 METAL CHIP 100 5% 1/16W
R412 1-218-977-11 METAL CHIP 100K 5% 1/16W
R413 1-216-864-11 SHORT CHIP 0
R414 1-216-864-11 SHORT CHIP 0
R416 1-218-947-11 METAL CHIP 330 5% 1/16W
R417 1-216-864-11 SHORT CHIP 0
R418 1-218-962-11 METAL CHIP 5.6K 5% 1/16W
R419 1-218-989-11 METAL CHIP 1M 5% 1/16W
R420 1-218-941-81 METAL CHIP 100 5% 1/16W
R421 1-218-941-81 METAL CHIP 100 5% 1/16W
R422 1-218-941-81 METAL CHIP 100 5% 1/16W
R423 1-218-941-81 METAL CHIP 100 5% 1/16W
R424 1-218-941-81 METAL CHIP 100 5% 1/16W
R425 1-218-941-81 METAL CHIP 100 5% 1/16W
R426 1-218-941-81 METAL CHIP 100 5% 1/16W
R427 1-218-941-81 METAL CHIP 100 5% 1/16W
R428 1-218-965-11 METAL CHIP 10K 5% 1/16W
R429 1-218-965-11 METAL CHIP 10K 5% 1/16W
R430 1-218-965-11 METAL CHIP 10K 5% 1/16W
R431 1-218-965-11 METAL CHIP 10K 5% 1/16W
R432 1-218-965-11 METAL CHIP 10K 5% 1/16W
R434 1-218-965-11 METAL CHIP 10K 5% 1/16W
R436 1-218-941-81 METAL CHIP 100 5% 1/16W
R438 1-218-977-11 METAL CHIP 100K 5% 1/16W
R439 1-218-989-11 METAL CHIP 1M 5% 1/16W
R441 1-218-941-81 METAL CHIP 100 5% 1/16W
R442 1-218-965-11 METAL CHIP 10K 5% 1/16W
R443 1-218-990-81 SHORT CHIP 0
R444 1-218-990-81 SHORT CHIP 0
R445 1-218-969-11 METAL CHIP 22K 5% 1/16W
R446 1-218-969-11 METAL CHIP 22K 5% 1/16W
R448 1-218-969-11 METAL CHIP 22K 5% 1/16W
R451 1-218-969-11 METAL CHIP 22K 5% 1/16W
R455 1-218-953-11 METAL CHIP 1K 5% 1/16W
R464 1-218-973-11 METAL CHIP 47K 5% 1/16W
R466 1-218-973-11 METAL CHIP 47K 5% 1/16W
R468 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
(CND)
R468 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(AEP, UK, AUS, HK, MY)
R469 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
(AUS)
R469 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
(CND)
R470 1-218-973-11 METAL CHIP 47K 5% 1/16W
R471 1-218-941-81 METAL CHIP 100 5% 1/16W
R472 1-218-941-81 METAL CHIP 100 5% 1/16W
R473 1-216-809-11 METAL CHIP 100 5% 1/10W
R474 1-218-973-11 METAL CHIP 47K 5% 1/16W
R476 1-218-981-81 METAL CHIP 220K 5% 1/16W
R477 1-218-973-11 METAL CHIP 47K 5% 1/16W
R479 1-218-941-81 METAL CHIP 100 5% 1/16W
R480 1-218-973-11 METAL CHIP 47K 5% 1/16W
R481 1-218-973-11 METAL CHIP 47K 5% 1/16W
(Suffi x-12) (See Note)
R502 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R503 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R504 1-218-990-81 SHORT CHIP 0
R505 1-218-977-11 METAL CHIP 100K 5% 1/16W
R510 1-218-941-81 METAL CHIP 100 5% 1/16W
R511 1-218-941-81 METAL CHIP 100 5% 1/16W
R513 1-218-973-11 METAL CHIP 47K 5% 1/16W
R514 1-218-973-11 METAL CHIP 47K 5% 1/16W
R515 1-218-973-11 METAL CHIP 47K 5% 1/16W
R516 1-218-953-11 METAL CHIP 1K 5% 1/16W
R517 1-218-953-11 METAL CHIP 1K 5% 1/16W
R518 1-218-953-11 METAL CHIP 1K 5% 1/16W
R519 1-218-941-81 METAL CHIP 100 5% 1/16W
R521 1-218-990-81 SHORT CHIP 0
R523 1-216-864-11 SHORT CHIP 0
R524 1-218-941-81 METAL CHIP 100 5% 1/16W
R525 1-218-953-11 METAL CHIP 1K 5% 1/16W
R526 1-216-864-11 SHORT CHIP 0
R527 1-216-864-11 SHORT CHIP 0
R528 1-216-864-11 SHORT CHIP 0
R529 1-208-637-11 METAL CHIP 12 0.5% 1/16W
R530 1-218-967-11 METAL CHIP 15K 5% 1/16W
Note: Refer to the “NEW/FORMER DISCRIMINATION OF MAIN, NETWORK,
FRONT-L AND AMP BOARDS” on page 4 for how to distinguish suffi x-12 of
MAIN board for Canadian model.
MAIN
