Sony UP-D898MD - 1-3. Board Location and Main Parts Location

1-5 (E)
UP-D898MD/X898MD
1-3. Board Location and Main Parts Location
1-3-1. Board Location
1-3-2. Main Parts Location
KY-711 board
SU-167 board
SE-1143 board
SE-1142 board
MA-195 board
Thermal head
DC motor
Stepping motor
Switching regulator
