Sony UP-D898MD - 1-12. Periodic Inspection and Periodic Replacement Parts; 1-13. Print Size

1-30 (E)
UP-D898MD/X898MD
1-12. Periodic Inspection and Periodic Replacement Parts
Parts that must be periodically inspected and replaced are as shown in the table below.
Parts name Description Refer to
Lithium battery
(UP-X898M only)
Replace the lithium battery every five years (rough standard) or when the
date is significantly shifted even after it is set.
Section 1-10
. Be sure to use IEC-60086-4 certificated products as a lithium battery.
Use a lithium battery (CR2032 type):1-528-174-72 when replacing the lithium battery. (Only UP-X898MD)
1-13. Print Size
1-13-1. Rough Standard of Print Size
1. When a video input signal is printed (Only UP-X898MD)
NTSC PAL
SCAN SIDE ASPECT Width Height Width Height
NORMAL OFF 1:1 90.0 93.8 90.0 93.0
4:3 90.0 70.5 90.0 68.5
ON 1:1 92.7 90.2 92.3 91.3
4:3 92.7 118.0 92.3 121.5
WIDE1 OFF 1:1 94.4 96.8 94.4 96.5
4:3 94.4 72.7 94.4 71.0
ON 1:1 96.0 94.4 95.7 95.8
4:3 96.2 124.3 95.7 127.3
WIDE2 OFF 1:1 95.5 99.7 95.5 98.2
4:3 95.5 75.0 95.5 72.8
ON 1:1 99.0 96.7 98.0 96.0
4:3 99.0 125.6 98.0 128.7
. The tolerance of length is width ?0.5 mm and height ?1.0 mm.
. When MULTI is valid, the size per screen is a value of 1/2, respectively.
2. When a digital (USB) input signal is printed
Paper size Width Height
960 x 1280 99.8 74.9
1280 x 1280 99.8 99.8
1920 x 1280 99.8 149.8
3840 x 1280 99.8 299.5
4096 x 1280 99.8 319.5
. The tolerance of length is width ?0.5 mm and height ?1.0 mm.
Paperfeed direction
Height
Width
