Sony UP-D898MD - Print Image Is Distorted in the Paper Feed Direction (Irregular Feeding)

2-8 (E)
UP-D898MD/X898MD
2-2-5. Print image is distorted in the paper feed direction (irregular feeding)
No
Yes
Replace the MA-195 board.
(Refer to Section 3-1.)
Print image is distorted in the paper
feed direction.
Does the stepping motor operate
normally and is the printing paper
normally fed after pressing the
[FEED] button?
Yes
No
No
Yes
Are the stepping motor drive
signals of CN1201 on the
MA-195 board changed
normally?
Is the connection of the harness
attached to the stepping motor
normal?
Check the connection of the
harness. If the symptom persists,
replace the stepping motor.
(Refer to Section 3-8.)
Replace the stepping motor.
(Refer to Section 3-8.)
Replace the MA-195 board.
(Refer to Section 3-1.)
