1-31 (E)
UP-D898MD/X898MD
1-13-2. Interval Between Print Screens
The interval of print screens is as shown in the table below by the setting of “--FEED” and “--BLANK” in
a COFIG menu.
--FEED --BLANK Interval (mm)
OFF _ 3.5 ?1.0
ON S 10.5 ?1.0
ON L 25.5 ?1.0
1-13-3. Blank in Horizontal Direction
The blank in a horizontal direction is not prescribed.
However, confirm that the printed image is not cut.
1-14. Lead-free Solder
All boards mounted in this unit use lead-free solder. Be sure to use lead-free solder when repairing the
boards of this unit. A lead free mark (LF) indicating that the solder contains no lead is printed on each
board.
(Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular
size.)
: LEAD FREE MARK
n
. The lead-free solder melts at a temperature about 40 dC higher than the ordinary solder, therefore, it is
recommended to use the soldering iron having a temperature regulator.
. The ordinary soldering iron can be used but the iron tip has to be applied to the solder joint for a slightly
longer time. The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so
be careful.
