Appendix B: Cable Information
Ethernet Connectors
110 | SmartBits 600x/6000x Installation Guide
SFP MSA Connectors
LAN-3320A, LAN-3321A, LAN-3324A, LAN-3325A, LAN-3327A, XD modules
GBIC (9-pin) Connector
LAN-3201B, LAN-3310A, LAN-3311A, LAN-3710AL, LAN-3710AE modules
Table B-3. SFP MSA Connector Pin Assignments
Pin Signal Pin Signal
20 TX GND 1 TX GND
19 TD- (TX DATA IN-) 2 TX FAULT
18 TD+ (TX DATA IN+) 3 TX DISABLE
17 TX GND 4 MOD-DEF2
16 VccTX 5 MOD-DEF1
15 VccRX 6 MOD-DEF0
14 RX GND 7 N/C
13 RD+ (R X DATA OUT-) 8 LOS
12 RD- (RX DATA OUT-) 9 RX GND
11 RX GND 10 RX GND
Table B-4. GBIC (9-pin) Connector Pin Assignments
Pin Signal
1 Rx Gnd
2 RD+ (Rx Data Out +)
3 RD- (Rx Data Out -)
4 Rx Signal Detect)
5V
cc
Rx
6V
cc
Tx
7 TD- (Tx Data In -)
8 TD + (Tx Data In +)
9 Tx Gnd
